MPC1000 V2 Operator’s Manual Rev 1.0
95
Loading a sequence
You can load a sequence file one by one.
01. Select the sequence file and load it. The Load a Se-
quence window will be displayed.
02. In the Load into field, select the destination sequence
number.
Select the sequence number to load the data to.
03. Press the [F5] (DO IT) key.
The MPC1000 will start loading the data.
Loading the ALL file
You can load the ALL file, which has sequence and song
data. When you load the ALL file, all the sequences
and songs, which are currently in the MPC1000, will
be replaced by the new data.
01. Select the ALL file and load it. The Load ALL
(SEQS&SONGS) File window will be displayed.
02. Press the [F5] (DO IT) key.
The MPC1000 will start loading the data.
Loading an individual sequence from the ALL file
•
You can load an individual sequence from the ALL file
01. Select the ALL file and load it. The Load ALL
(SEQS&SONGS) File window will be displayed.
02. Press the [F3] (SEQ) key.
The Load a Sequence window will be displayed.
03. In the Load file field, select the sequence to load.
In the Load file field, you can select a sequence data
in the ALL file.
04. In the Load into field, select the destination sequence.
Select the sequence number to load the data to.
05. Press the [F5] (DO IT) key.
The MPC1000 will start loading the data.
• Loading only the effect set from the ALL file
The ALL file has effect set file, which has the effect
setting information. You can load only the effect
set from the ALL file.
01. Select the ALL file and load it. Load ALL
(SEQS&SONGS) File window will be displayed.
02. Press the [F2] (EFFECT) key.
The Load Effect File window will be displayed.
03. In the Load file field, select the effect set to load.
04.
In the Load into field, select the destination effect set.
Select the effect set number to load the data to.
If you select ALL in the Load file field, the current
effect set in the unit will be replaced by the data
from the ALL file.
05. Press the [F5] (DO IT) key.
The MPC1000 will start loading the data.
Loading a folder
You can load a folder and load all the files within the
folder at the same time. You can load program, sample,
and ALL files.
01. Select a folder and load it. The Load Folder window
will be displayed.
02.
Make a setting in the Replace same files in memory field.
You can set how to handle the file when you al-
ready have the data with the same name as the load-
ing file in the unit.
NO The MPC1000 will not load the file with
the same name.
YES The MPC1000 will overwrite the data in
the unit by the loaded file.
03. Press the [F5] (DO IT) key.
The loading will begin.
•
Loading the folder after deleting the data
in the memory
When you press the [F2] (CLEAR) key instead of
the [F5] (DO IT) key in step 3, you can clear the
MPC1000’s memory and load the selected folder.
01. In the step 3, press the [F2] (CLEAR) key instead of
the [F5] (DO IT) key.
The CAUTION window will be displayed. If you
press the [F5] (DO IT) key, the MPC1000 will start
loading the folder after it clears all its internal memory.
Note : If you do this operation, all the data saved in the unit will
be deleted.
Note : If the folder has several ALL file, the MPC1000 will load
only one of them.
