June 2007 Installing the Hardware 9
Installing Combo Port SFPs
OmniSwitch 6800 Series switches offer Gigabit Ethernet
combo ports, located on the front panel. These combo ports
support hot-swappable fiber Small Form-Factor Pluggables
(SFPs). For instructions on installing and removing combo
port SFPs, refer to the instruction card provided with the SFP
product.
Note. Combo port preferences are user-configurable via
the system software. Refer to the “Configuring Ethernet
Ports” chapter in the OmniSwitch 6800/6850/9000
Network Configuration Guide for complete details.
Note. For further details regarding supported SFP and
XFP transceivers, refer to the OmniSwitch Transceivers
Guide.
Installing Backup Power Supply
Components
For detailed information on installing backup power supply
components—including the backup power supply shelf, power
supply modules, chassis daughtercard, connector cables, and
power cords—refer to the OmniSwitch 6800 Series Hardware
Users Guide.
For information on connecting stacked switches, refer to the
OmniSwitch 6800 Series Hardware Users Guide.
