Booting a Standalone Switch
The OmniSwitch 6800 Series switch does not use an on/off
switch. The power cord is the switch’s only connect/discon-
nect device. The power connector socket is located on the
switch’s rear panel. For more information, refer to the
OmniSwitch 6800 Series Hardware Users Guide.
To boot the switch, plug the power cord (provided) into the
power connector socket at the switch’s rear panel. Next, plug
the power cord into an easily-accessible power source, such as
a grounded AC outlet or an Uninterruptible Power Supply
(UPS).
The switch immediately begins the boot process. Allow a few
moments for the switch to boot completely, then verify the
status of all LEDs on the switch’s front panel. A successful
boot for a standalone switch displays the following LED
states:
If any of the LED state differs from the states shown in the
table above, refer to the OmniSwitch 6800 Series Hardware
Users Guide for more information. Contact Alcatel-Lucent
Customer Support if the unexpected LED state persists.
For information on booting stacked configurations and
dynamic slot numbering, refer to the OmniSwitch 6800 Series
Hardware Users Guide.
Booting OmniSwitch 6800 Series Switches
LED States for a Standalone Switch
OK Solid green
PRI Solid green
PWR Solid green
BPS Solid amber if no operational backup
power supply (BPS) is attached; solid
green if an operational BPS is
attached.
FAN Solid green
TMP Solid green
XFP1 Off
XFP2 Off
Slot Indicator 1–8 (non-blinking), depending on the
slot number value in the boot.slot.cfg
file. See the OmniSwitch 6800 Series
Hardware Users Guide for detailed
information. The default value is 1.
LED States for a Standalone Switch
