Operation Manual

Allen & Heath 4 WZ
4
16:2 and 12:2 User Guide
Important Mains plug wiring instructions.
The console is supplied with a moulded mains plug fitted to the AC mains power lead. Follow the instructions
below if the mains plug has to be replaced. The wires in the mains lead are coloured in accordance with the fol-
lowing code:
TERMINAL WIRE COLOUR
European USA/Canada
L LIVE BROWN BLACK
N NEUTRAL BLUE WHITE
E EARTH GND GREEN & YELLOW GREEN
Damage : To prevent damage to the controls and cosmetics avoid placing heavy objects on the
control surface, scratching the surface with sharp objects, or rough handling and vibra-
tion.
Environment : Protect from excessive dirt, dust, heat and vibration when operating and storing.
Avoid tobacco ash, smoke, drinks spillage, and exposure to rain and moisture. If
the console becomes wet, switch off and remove mains power immediately. Allow to
dry out thoroughly before using again.
Cleaning : Avoid the use of chemicals, abrasives or solvents. The control panel is best cleaned
with a soft brush and dry lint-free cloth. The faders, switches and potentiometers are
lubricated for life. The use of electrical lubricants on these parts is not recommend-
ed. The fader and potentiometer knobs may be removed for cleaning with a warm
soapy solution. Rinse and allow to dry fully before refitting them.
Transporting : The console may be transported as a free-standing unit or mounted in a rack or
flightcase. Protect the controls from damage during transit. Use adequate packing if
you need to ship the unit.
Hearing : To avoid damage to your hearing do not operate any sound system at excessively
high volume. This also applies to any close-to-ear monitoring such as headphones.
Continued exposure to high volume sound can cause frequency selective or wide
range hearing loss.

General Precautions
!
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter
E or with the Earth symbol. This appliance must be earthed.
The wire which is coloured Blue must be connected to the terminal in the plug which is marked with the letter N.
The wire which is coloured Brown must be connected to the terminal in the plug which is marked with the letter L.
Ensure that these colour codes are followed carefully in the event of the plug being changed.
Safety Instructions
