Installation Guide

Table Of Contents

18,24,30,36

2x 9/16" Glass Holes

Mounting Plate

1/8-27 NPS

1/8-27 Hex Nut

Step 1:

Determine your desired location for installation and make 2 marks for the location for mounting.. Drill Ø9/16" hole at each of

the marks.

Drill Ø9/16" Holes into Glass Door

Mount Door Pull to Door as below.

Step 2:

Shower Door Towel Bar Mounting

Glass Door

Plastic Washer

Clear Vinyl Bushing

Backplate

DT-41SM

INSTALLATION INSTRUCTIONS

No portion of this document or any artwork contained herein should reproduced in any way without the written conset of ALLIED BRASS INC.
