How the Switch Reports Problems
The switch detects and processes errors as follows:
❑ The LEDs indicate problems with the port and power.
Table 3-1 describes the switch LEDs.
❑ In a TCP/IP environment, if you have configured the software
correctly, the management software triggers an SNMP trap
message. As a result, the software then sends traps to alert the
network manager when a trigger occurs. This type of software
configuring allows the network administrator/manager to
pro-actively monitor their network.
Table 3-1 lists and describes the switch LEDs.
Table 3-1 LEDs
Name Color State Description
Fault Red ON
OFF
Indicates that the management software is
malfunctioning, a problem exists with the serial
interface, diagnostics is running, or a hardware
problem.
Indicates no problem.
Power Green ON
OFF
Indicates that power is being applied to the switch
Indicates the voltage has dropped below acceptable
levels or the power cord is loose.
Link OK
(Ethernet)
Green ON
OFF
Indicates that there is a good physical link with a
device.
Indicates the physical link is broken.
Activity
(TX/RX)
Green Flashing Indicates the Ethernet port is receiving/transmitting
packets.
