- Table of Contents
- Preface
- AT-3714F, AT-3726 Hardware Description
- Installing the Switch
- Verifying Switch Package Contents
- Safety Information
- Preparing the Site
- Rack Mounting the Unit
- Media Dependent Adapters
- Figure23 AT-3701 and AT-3701F/SC MDA Front Pan...
- Verifying Package Contents
- Media Dependent Adapter Features
- Table23 Media Dependent Adapter Features
- Installing a Media Dependent Adapter
- 1. Disconnect the switch’s power cord.
- 2. Unscrew the three Phillips head screws on the b...
- 3. The standoff on the MDA serves as a guide to sl...
- 4. Slide the MDA into its empty slot making sure t...
- 5. Attach the female 50-pin female connector to it...
- Figure24 Guiding the MDA (AT-3701) Standoff in...
- Figure25 Connecting the 50-Pin Female Connecto...
- MDA LEDs
- Installing a Media Dependent Adapter
- Table24 Media Dependent Adapter LEDs
- Troubleshooting
- Switch Configurations
- AppendixA
- AppendixB
Technical Specifications
B-2
Media Dependent Adapter Cabling Distances
Table B-3 lists the maximum cable distances for the AT-3714F,
AT-3726 Switch Media Dependent Adapter (MDA).
Table B-2 RJ45 Pin Assignments for AT-3714F (Mirror port) and AT-3726
Pin Number Function
1 RD+
2 RD-
3 TD+
4 Unused
5 Unused
6 TD-
7 Unused
8 Unused
Table B-3 MDA Maximum Cable Distances
MDA Ethernet Type Maximum Distance
AT-3701F/SC SC (100Base) 1.25 miles (2 km for full duplex,
412 M for half duplex) 50/125
and 62.5/125 micron multimode
fiber cable
AT-3701 RJ45 (10/100Base) 330 ft. (100m), twisted pair
Category 5 UTP
