Allied Telesis www.alliedtelesis.com

Datasheet | Routers

AT-AR750S

Secure VPN Router

AT-AR750S

2 x WAN 10/100BASE-T ports

5 x LAN 10/100BASE-T ports

2 x PICs

1 x Asynchronous console / Modem port

Secure Modular Routing Solution

The AT-AR750S has been designed with the

needs of small to medium enterprises/businesses

(SME/SMB) or branch office businesses in mind.

The AT-AR750S offers significant advances in

processing performance, Quality of Service (QoS),

routing, remote connectivity and security.

Extensive VPN Cabability

The AT-AR750S provides extensive IPSec-based

VPN capability, allowing the interconnection of

offices, remote tele-workers, and other users

who require secure access to a corporate

network.The integrated hardware acceleration,

standard on the AT-AR750S, maximizes

encryption throughput and removes the need

to purchase a hardware upgrade package.The

AT-AR750S is also compatible with industry

standard IPSec VPN clients.

Security

In addition to hardware-based encryption, the

AT-AR750S comes with other advanced

security features such as traffic filtering with

event logging.Traffic filtering uses the source

and destination address, port, protocol and TCP

packet type to provide control over traffic that

passes through the AT-AR750S. A Stateful

Inspection Firewall provides an increased level

of security and complements the packet filtering

function. HTTP and SMTP proxies on the

AT-AR750S provide improved control over web

and mail communications.

Quality of Service

Allied Telesis’ QoS implementation enables the

AT-AR750S to dynamically identify high priority

voice, video and application traffic, so that

appropriate service levels can be

maintained in congested networks. Advanced

QoS allows voice, video, and data traffic to have

QoS applied within individual IPSec tunnels,

over GRE, as well as IPv6 to IPv4 tunnels.

Performance

The AT-AR750S provides superior performance

over other secure VPN routers in this market

space. While most secure routers have Stateful

Firewalls with NAT, QoS, and IPsec VPN

termination capability, very few can perform all

three functions and still provide excellent

performance with the mixed packed sizes seen

in real networks. The AT-AR750S has been

designed to meet real network needs.

Stateful Firewall inspection, NAT and QoS:

>50Mbps @ 64 byte packets

Stateful Firewall inspection, NAT, QoS, IPsec

VPN (with AES 256 bit encryption):

>35Mbps @ 72 byte packets

The AT-AR750S can achieve up to 195 Mbps

IPsec throughput with bidirectional traffic.

This level of performance enables secure site-

to-site VPNs over multiple WAN interfaces

while still firewalling the local network across

multiple LAN ports.

Comprehensive Management and

Configuration

The AT-AR750S comes with a comprehensive

suite of management features and is also

compatible with SNMP-based management

packages. An extensive command set is available

via the Command Line Interface (CLI), and a

browser-based Graphical User Interface (GUI) is

also provided to simplify the AT-AR750S'

configuration and management.The GUI provides

access to default set-ups in key management

areas and provides access to regional settings.

Allied Telesis’ SNMP support extends to SNMPv3

to provide secure management.

Key Features

Hardware

• 2 x 10/100 WAN interfaces

• 2 x Port Interface Cards (PICs)

• 5 x 10/100BASE-T switched LAN ports

• 1 x Asynchronous port / Modem Port

• DMZ port: configurable on any of the WAN/LAN ports

• RoHS Compliant

Security

• IP Filtering

• Stateful Inspection Firewall

• 802.1x

• Authentication: RADIUS,TACACS, MD5, PAP, CHAP

VPN/Encryption

• NAT-T

• AES, DES, 3DES encryption

• 5,000 configured IPsec VPN tunnels (250 active tunnels)

• HW accelerated IPsec VPN >35Mbps@72byte

packets (with AES 256 bit encryption)

• Up to 195 Mbps IPsec throughput with large packets

Manageability

• Web based GUI

• CLI management

• SNMPv3

• IP QoS

Extensive routing support, including:

• RIPv1 and v2

• OSPFv1 and v2

• GRE, L2TP

• IPX

• VRRP

• RIPng

• IPv6 – optional

• BGP-4 – optional

Multicast routing protocols, including:

• PIM-DM

• PIM-SM

• DVMRP

• IGMPv2

• IGMP Snooping

• IPv6 Multicast – optional

• PIM6

• MLD

Support for traditional network protocols,

including:

• X.25

• Frame Relay

Summary of content (5 pages)

PAGE 1
Datasheet | Routers AT-AR750S Secure VPN Router AT-AR750S 2 x WAN 10/100BASE-T ports 5 x LAN 10/100BASE-T ports 2 x PICs 1 x Asynchronous console / Modem port maintained in congested networks. Advanced QoS allows voice, video, and data traffic to have QoS applied within individual IPSec tunnels, over GRE, as well as IPv6 to IPv4 tunnels.
PAGE 2
AT-AR750S | Secure VPN Router WAN Load Balancing Management The AT-AR750S’ WAN Load Balancer enables the router to combine bandwidth from multiple WAN connections for increased throughput, redundancy and reliable WAN connectivity. When a router simultaneously connects to multiple WAN networks, the WAN Load Balancer will distribute the traffic based on any one of a number of selectable balancing algorithms.
PAGE 3
AT-AR750S | Secure VPN Router Standards and Protocols Software Release 2.9.
PAGE 4
AT-AR750S | Secure VPN Router RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering and Virtual LAN Extensions (VLAN) RFC 2790 Host MIB RFC 2819 RMON (groups 1,2,3 and 9) RFC 2856 Textual Conventions for Additional High Capacity Data Types RFC 2863 The Interfaces Group MIB RFC 3164 Syslog Protocol RFC 3289 Management Information Base for the Differentiated Services Architecture CDP RFC 3410 Introduction and Applicability Statements for Internet-Standard Management Fra
PAGE 5
AT-AR750S | Secure VPN Router ACA TS 013.2:1990 General Requirements for Customer Equipment Connected to ISDN Basic Rate Access, Vol 2: Conformance Testing Specifications ACA TS 014.1:1990 General Requirements for Customer Equipment Connected to ISDN Primary Rate Access, Vol 1: Customer Access Interface Specifications ACA TS 014.
