Instruction Manual

Chapter 7: Port Parameter Commands
146 Section I: Basic Operations
SHOW SWITCH COUNTER
Syntax
show switch counter
Parameters
None.
Description
This command displays operating statistics, such as the number of
packets received and transmitted, and the number of CRC errors, for the
entire switch. An example of the display is shown in Figure 12.
Figure 12. SHOW SWITCH COUNTER Command
The command provides the following information:
Bytes Rx
Number of bytes received by the switch.
Bytes Tx
Number of bytes transmitted by the switch.
Frames Rx
Number of frames received by the switch.
Frames Tx
Number of frames transmitted by the switch.
Bcast Frames Rx
Number of broadcast frames received by the switch.
Port: All
Bytes Rx ......... 983409801 Bytes Tx ......... 965734443
Frames Rx ........ 815423 Frames Tx ........ 691396
Bcast Frames Rx... 107774 Bcast Frames Tx .. 1853
Mcast Frames Rx .. 11429 Mcast Frames Tx .. 0
Frames 64 ........ 110509 Frames 65-127 .... 15192
Frames 128-255 ... 1928 Frames 256-511 ... 442
Frames 512-1023 .. 157796 Frames 1024-1518.. 1221024
CRC Error ........ 0 Jabber ........... 0
No. of Rx Errors . 0 No. of Tx Errors . 0
UnderSize Frames . 0 OverSize Frames .. 0
Fragments ........ 0 Collision ........ 0
Frames 1519-1522 . 0 Dropped Frames ... 0
