Examples
The following command sets ports 4 to 6 to the authenticator role. The
authentication method is set to 802.1x, meaning that the supplicants must
have 802.1x client software and provide a username and password, either
automatically or manually, when logging on and during reauthentications.
The operating mode is set to Single and the piggy back mode to disabled.
At these settings, only one supplicant can use each port. After a supplicant
logs on, access by any other client to the same port is denied:
set portaccess=8021x port=4-6 role=authenticator mode=single
piggyback=disabled
The next command is identical to the previous example, except the
authentication method is MAC address-based, meaning the authenticator
ports use the MAC addresses of the supplicants as the usernames and
passwords. With MAC address-based authentication, an authenticator
port automatically extracts the MAC address from the initial frames
received from a supplicant and sends it to the RADIUS server. The
supplicants do not need 802.1x client software. Again, as in the previous
example, since the operating mode is Single and the piggy back mode is
disabled only one supplicant can use each port.
set portaccess=macbased port=4-6 role=authenticator
mode=single piggyback=disabled
Note
The remaining examples are limited to the 802.1x authentication
method, but apply equally to the MAC address-based authentication
method.
The following command sets port 12 to the authenticator role and the
operating mode to Single. The difference between this and the previous
example is the piggy back mode is enabled. This configuration is
appropriate when an authenticator port is supporting multiple clients, such
as when a port is connected to an Ethernet hub, and you do not want to
give each supplicant a separate username and password combination on
the RADIUS server. With the piggy back mode enabled, all of the clients
connected to the port can access it after one supplicant logs on:
set portaccess=8021x port=12 role=authenticator mode=single
piggyback=enabled
The following command sets port 22 to the authenticator role and the
operating mode to Multiple. This configuration is also appropriate where
there is more than one supplicant on a port. But an authenticator port in
the Multiple mode requires that all supplicants have their own username
and password combinations on the RADIUS server and that they log on
before they can use the authenticator port on the switch:
