AT-S62 Management Software Web Browser Interface User’s Guide
Section II: Advanced Operations 133
LOCAL6
LOCAL7
Each setting represents a predefined RFC 3164 numerical code. The
code mappings are listed in Table 5.
For example, selecting LOCAL2 as the facility level assigns the
numerical code of 18 to all events sent to the syslog server by the
switch.
Module Selections
The originating module of the events to be sent to the syslog server.
The AT-S62 management software consists of a number of modules,
each responsible for a different part of switch operation. You can use
this parameter to instruct the switch to send only those events that
originated from selected modules. The default is ALL, which sends the
events from all modules. The modules are defined in Table 3 on
page 125. To select more than one module, hold down the Ctrl key
when making your selections.
6. After configuring the syslog server definition, click Apply.
The switch adds the new syslog server definition to the Event Log tab
and immediately begins sending events to the server if you enabled
the Message Generation option.
7. To permanently save the change, click the Save Config menu
selection.
Table 5. Numerical Code and Facility Level Mappings
Numerical
Code
Facility Level Setting
17 LOCAL1
18 LOCAL2
19 LOCAL3
20 LOCAL4
21 LOCAL5
22 LOCAL6
23 LOCAL7
