Section I: Basic Operations 61

Chapter 4

SNMPv1 and SNMPv2c Community

Strings

This chapter explains how to activate SNMP management on the switch

and how to create, modify, and delete SNMPv1 and SNMPv2c community

strings.

This chapter contains the following procedures:

 “Enabling or Disabling SNMP Management” on page 62

 “Creating a New SNMPv1 or SNMPv2c Community String” on page 64

 “Modifying an SNMPv1 or SNMPv2c Community String” on page 67

 “Deleting an SNMPv1 or SNMPv2c Community String” on page 69

 “Displaying the SNMP Status and Community Strings” on page 70

Note

For background information, refer to Chapter 5, “SNMPv1 and

SNMPv2 Configuration” in the AT-S62 Management Software

Menus Interface User’s Guide.
