Section II: Advanced Operations 119

Chapter 10

Event Logs and Syslog Client

This chapter describes how to view switch activity by displaying and saving

the contents of the event logs. It also explains how to send events to

syslog servers on your network by creating syslog output definitions.

Sections in the chapter include:

 “Working with the Event Logs” on page 120

 “Working with Syslog Output Definitions” on page 129

Note

The event logs, even when disabled, log all AT-S63 initialization

events that occur when the switch is reset or power cycled. Any

switch events that occur after AT-S63 initialization are entered into

the logs only if the event log feature is enabled, which is the default

setting for this feature.
