AT-S63 Management Software Web Browser User’s Guide
Section II: Advanced Operations 123
Display Order
Controls the chronological order of the events in the display. Options
are:
Chronological - Lists the events starting with the oldest events. This
is the default.
Reverse Chronological - Lists the events starting with the most
recent events.
Mode
Controls the format of the events in the display. Options are:
Normal - Displays an event’s time of occurrence, module originator,
severity, and description for each event. This is the default. An
example of Normal mode is shown in Figure 34 on page 125.
Full - Displays the same information as Normal, plus the file name,
line number, and event ID. An example of Full mode is shown in
Figure 35 on page 126.
Module Selections
Specifies the AT-S63 software modules whose events will be
displayed. The modules are listed in Table 1. You can select more than
one module by using the Ctrl key as you make your selections. The
default is All.
Table 1. AT-S63 Software Modules
Name Description
ALL All modules
ACL Port access control lists
CFG Switch configuration file
CLASSIFIER Classifiers used by ACL and QoS
CLI Command line interface commands
DOS Denial of Service defense
ENCO Encryption keys
ESTACK Enhanced stacking
EVTLOG Event log
FILE File system
GARP GARP VLAN Registration Protocol
HTTP Web server
IGMPSNOOP IGMP snooping
