User guide

AT-S63 Management Software Web Browser User’s Guide
Section II: Advanced Operations 131
Error - Sends only error event messages. Error messages indicate that
the switch operation is severely impaired.
Warning - Sends only warning event messages. These messages
indicate that an issue may require manager attention.
Information - Sends only informational event messages. Informational
messages display useful information that you can ignore during normal
operation.
Debug - Sends debug event messages. These events provide detailed
high-volume information that is intended only for technical support
personnel.
Type
Specifies the type of the output definition. The only option is Syslog.
Syslog Server IP Address
Specifies the IP address of the syslog server.
Facility Level
Specifies the numerical code to be added to the entries when sent to
the syslog server. The facility levels are listed in Table 3.
Note
For further information about the syslog facility levels, refer to
Chapter 12, “Event Logs and Syslog Servers” in the AT-S63
Management Software Menus Interface User’s Guide.
Module Selections
Specifies the AT-S63 Management Software module(s) whose events
are to be sent to the syslog server. To select more than one, use the
Ctrl key when making your selections. The default is All. For a list of
modules, refer to Table 1 on page 123.
6. Click Apply.
The switch creates the new log output server definition and
immediately begins sending events to the server, provided that the
Output Status option for the definition is enabled and the log feature on
the switch is also enabled.
Table 3. Default Syslog Facilities
Facility Mapped Event Log Modules and Events
Default This setting uses the functional groupings as
defined in the RFC 3164 standard.
local 1 through
local 7
These settings assign a specific identifier to the
events.
