User guide

Chapter 11: Classifiers
142 Section II: Advanced Operations
Modifying a Classifier
This procedure explains how to modify a classifier.
Note
If the classifier to be modified is currently assigned to an ACL or
QoS policy that has been assigned to a switch port, you must
remove the port assignments from the ACL or policy before you can
modify the classifier. After you have finished modifying the classifier,
you can reassign the ports again to the ACL or QoS policy.
To modify a classifier, perform the following procedure:
1. From the home page, select Configuration.
2. From the Configuration menu, select the Network Security or
Services option. The Classifier tab is accessible from both menu
selections.
3. Select the Classifier tab.
The Classifier tab is shown in Figure 40 on page 136.
4. Click the dialog circle next to the classifier to be modified and click
Modify. You can modify only one classifier at a time. An example of
the Modify Classifier page is shown in Figure 43.
Figure 43. Modify Classifier Page
5. Modify the parameters as necessary. For parameter descriptions, refer
to “Configuring a Classifier” on page 136.
