Chapter 17: SNMPv3

234 Section III: SNMPv3

Note

The Row Status parameter is a read-only field in the web browser

interface. The Active value indicates the SNMPv3 SecurityToGroup

Table entry takes effect immediately.

7. Click Apply to update the SNMPv3 SecurityToGroup Table.

8. To permanently save your changes, select the Save Config option in

the Configuration menu.
