Chapter 18: Spanning Tree and Rapid Spanning Tree Protocols
276 Section IV: Spanning Tree Protocols
Configuring STP
This section contains the following procedures:
”Configuring STP Bridge Settings”, next
“Configuring STP Port Settings” on page 279
“Displaying the STP Settings” on page 280
“Resetting STP to the Default Settings” on page 282
Caution
The bridge provides default STP parameters that are adequate for
most networks. Changing them without prior experience and an
understanding of how STP works might have a negative effect on
your network. You should consult the IEEE 802.1d standard before
changing any of the STP parameters.
Configuring STP
Bridge Settings
To configure STP bridge settings, perform the following procedure:
1. From the Home page, select Configuration.
2. From the Configuration menu, select the Layer 2 option.
3. Select the Spanning Tree tab.
The Spanning Tree tab is shown in Figure 109 on page 274.
4. Click Configure.
