AT-S63 Management Software Web Browser User’s Guide

Section VI: Port Security 357

Configuring Authenticator Port Parameters

To configure authenticator port parameters, perform the following

procedure:

Note

The role of a port must be set to authenticator before the parameters

can be configured. For instructions, refer to “Setting Port Roles” on

page 354.

1. From the home page, select Configuration.

2. From the Configuration menu, select the Network Security option.

3. Select the 802.1x Port Access tab.

The 802.1x Port Access tab is shown in Figure 144 on page 354.

4. In the switch image, click the authenticator port to be configured. You

can configure more than one authenticator port at a time. The selected

port turns white.

5. Click Settings.
