AT-S63 Management Software Web Browser User’s Guide
Section VI: Port Security 363
Configuring Supplicant Port Parameters
To configure supplicant port parameters, perform the following procedure:
Note
The role of a port must be set to supplicant before the parameters
can be configured. For instructions, refer to “Setting Port Roles” on
page 354.
1. From the home page, select Configuration.
2. From the Configuration menu, select the Network Security option.
3. Select the 802.1x Port Access tab.
The 802.1x Port Access tab is shown in Figure 144 on page 354.
4. Click the supplicant port to be configured. You can configure more
than one supplicant port at a time. The selected port turns white.
5. Click Settings.
The Supplicant Parameters page is shown in Figure 146.
Figure 147. Supplicant Parameters Page
6. Configure the following parameters as needed:
Auth Period
Specifies the period of time in seconds that the supplicant waits for a
reply from the authenticator after sending an EAP-Response frame.
The range is 1 to 300 seconds. The default is 30 seconds.
