Modifying a Port Mirror
To modify a port mirror, perform the following procedure:
1. From the home page, select Configuration.
2. From the Configuration menu, select the Layer 1 option.
3. Select the Port Mirroring tab.
The Port Mirroring tab is shown in Figure 26 on page 96.
4. Click Modify.
The Modify Mirror page is shown in Figure 27 on page 97.
5. Change the ports of the port mirror, as needed. Clicking a port toggles
it through the possible settings, which are as follows:
6. Click Apply.
The changes to the port mirror are now active on the switch.
7. To permanently save your changes, select the Save Config option in
the Configuration menu.
The destination (mirror) port. There can be only one
destination port. To change the destination port, you must
first change the current destination port to one of the other
settings.
A source port. The port’s ingress traffic is mirrored to the
destination port.
A source port. The port’s egress traffic is mirrored to the
destination port.
A source port. The port’s ingress and egress traffic is
mirrored to the destination port.
Not part of a port mirror.
