Secton V: Virtual LANs 335

Chapter 21

Port-based and Tagged VLANs

This chapter explains how to create, modify, and delete port-based and

tagged VLANs. This chapter also explains how to select a multiple VLAN

mode.

This chapter contains the following sections:

 “Creating a New Port-Based or Tagged VLAN” on page 336

 “Modifying a VLAN” on page 341

 “Deleting a VLAN” on page 343

 “Selecting a VLAN Mode” on page 344

 “Displaying VLANs” on page 345

Note

For background information on VLANs, refer to the AT-S63

Management Software Menus Interface User’s Guide.
