AT-S63 Management Software Web Browser User’s Guide
Section III: SNMPv3 155
Figure 51. Add New SNMPv3 Notify Page
5. Configure the parameters, described in Table 26, for the new entry and
click the Apply button.
Table 26. SNMPv3 Notify Table Parameters
Parameter Description
Notify Name The name to be associated with this trap message. The name
can be up to 32 alphanumeric characters. For example, you
might define a trap message for hardware engineering and
enter a value of “hardwareengineeringtrap” for the Notify
Name.
Notify Tag The name of a Notify Tag. The name can be up to 32
alphanumeric characters. This parameter is added to the Tag
List parameter in the SNMPv3 Target Address Table, which
defines the IP addresses of the devices to receive the traps or
inform messages.
Notify Type The possible values are:
T-Trap - This option sends traps. SNMPv3 does not expect
hosts to respond to traps.
I-Inform - This option sends inform messages. SNMPv3
expects hosts to respond to inform messages.
Storage Type The storage method of the entry. The possible values are:
V-Volatile - This setting prevents the stack from saving the
entry in the master configuration file. An entry with this storage
type is discarded the next time the stack is reset or powered
off.
