Specifications
Pearleye P-030 LWIR
Interface IEEE 802.3 1000baseT
Resolution 640 x 480
Spectral range LWIR, 8 - 14 µm
Sensor ULIS UL 04 17 1
Sensor type Microbolometer
Sensor size No standard size
Cell size 25 μm x 25 μm
Lens mount M65 x 0.5
Max frame rate at full resolution 24 fps
Temperature measurement -20 °C ... +80 °C
NETD < 80 mK@ 303 K @ f/1.0
A/D 14 bit
Output
Bit depth 14 bit
Mono modes Mono14
Operating conditions/Dimensions
Operating temperature 0°... +35 °C (ambient)
Power requirements (DC) 12 V
Power consumption (12 V) 18 W
Mass 760 g
Body Dimensions
(L x W x H in mm)
133.7 x 90 x 86 mm, incl. lens and connectors
Regulations CE, RoHS (2002/95/EC)
Download Technical drawing (click here)
