WMP-N06 WMP-N06 User’s Guide
WMP-N06 FCC Statement : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
WMP-N06 IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.
WMP-N06 1.0 Scope 1.1 Document This document is to specify the product requirements for 802.11b/g MIMO Mini-PCI Card. This MIMO Mini-PCI Card is based on Atheros AR5008 chipset that complied with 802.11n draft 1.0 standard from 2.4~2.5GHz, and it can be used to provide up to 11Mbps for IEEE 802.11b and 54Mbps for 2.4GHz IEEE 802.11g to connect your wireless LAN. With seamless roaming, fully interoperability and advanced security with WEP standard, 802.
WMP-N06 # Feature 2.1.1.5 2.1.1.6 Data Rate Media Access Protocol Transmitter Output Power Receiver Sensitivity 2.1.1.7 2.1.1.8 Detailed Description 14 channels for Japan 11, 5.5, 2, and 1Mbps CSMA/CA with ACK 2dBi Dipole Antenna: Typical 28dBm 3dBi Dipole Antenna: Typical 28dBm Typical –84dBm for 11Mbps @ 8% PER Typical –90dBm for 2Mbps @ 8% PER 2.1.2 IEEE 802.11g Section # Feature 2.1.2.1 2.1.2.2 Standard Radio and Modulation Schemes Operating Frequency Channel Numbers 2.1.2.3 2.1.2.4 2.1.2.
WMP-N06 # Feature Detailed Description 15dBm MCS - Typical 5, 13 29.5dBm 2dBi DipoleatAntenna: 3dBi DipoleatAntenna: 11dBm MCS - Typical 6, 14 29.5dBm 2.1.3.
WMP-N06 2.2.2 Configuration # Feature 2.2.2.1 ESS ID 2.2.2.2 Network Type 2.2.2.3 Power Save 2.2.2.4 RTS Threshold 2.2.2.5 2.2.2.6 Fragment Threshold Transmission Speed 2.2.2.7 Roaming Detailed Description Input an SSID number if the roaming feature is enabled Supports for ASCII printable characters. Ad-hoc Mode and 802.
WMP-N06 # Feature 2.5.3 Quality Detailed Description The product quality is followed-up by ALPHA factory quality control system 2.6 Environmental Requirements # Feature 2.6.1 Operating Temperature Conditions Non-Operating Temperature Conditions 2.6.2 2.6.3 2.6.4 Operating Humidity conditions Non-Operating Humidity Conditions Detailed Description The product is capable of continuous reliable operation when operating in ambient temperature of 0 ℃ to +55℃.
WMP-N06 Test Environment Diagram/測試環境圖示 Fixed Attenuator (30dB) * 3 pcs Splitter (1 對 3) IP: 192.168.100.
WMP-N06 Normal Test Operating Procedure/一般作業用測試操作程序 1. Testing Steps: 8 steps in total 1. 測試步驟: 共 8 個步驟 註 1:測試前請先安裝待測物之 driver. 註 2:測試前請先依照附錄(Test Programming Setup / 測試程式設定說明)設定 [Step 1] Run ” BC_LOG.exe ” at DUT (see Figure 1) to open test window (see Figure 2). [步驟 1] 執行 DUT 端上的” BC_LOG.exe ”(如圖 1)開啟如圖 2 測試畫面。 Ex: C:\Program Files\LitePoint\IQfact\ART_MIMO_1WMPN06…B1G\MINIPCI_2071\ BC_LOG.
WMP-N06 [Step 2] Run ” GUI.exe ” at DUT (see Figure 3) to open test window (see Figure 4). [步驟 2] 執行 DUT 端上的” GUI.exe ”(如圖 3)開啟如圖 4 測試畫面。 Ex: C:\Program Files\LitePoint\IQfact\ART_MIMO_1WMPN06…B1G\MINIPCI_2071\ GUI.
WMP-N06 [Step 3] Then Kevin Serial number (see Figure 5) [步驟 3] 鍵入 Serial Number (如圖 5 (Figure 5) [Step 4] (a) Plug DUT into MINI PCI / CARD BUS Interface (b) Plug RF Cable on DUT antenna three point and user a special line (MAIN-From Left to Right 0.1.2) [步驟 4] (a) 將待測物插入 MINI PCI / CARD BUS Interface 介面。 (b) 將待測物接上測試線於三個天線端,請使用專用測試線。(MAIN-由左至右 0.1.2) [Step 5] Click “Run Production Test Software” to begin test.
WMP-N06 [Step 6] Testing.
WMP-N06 [Step 7] When test finish, it will show “PASS”(see Figure 8). [步驟 7] 當測試完成,會出現’’PASS”的視窗(圖 8)。 (Figure 8) [Step 8] When show “PASS”, click “ Test ” and change the next one to continue (see Figure 8).
WMP-N06 Test Program setup / 測試程式設定 [步驟 1] 尋找程式中” IQ_attn.txt ” 檔案(如圖 1), (Ex: Ex: C:\Program Files\LitePoint\IQfact\ART_MIMO_1WMPN06…B1G\MINIPCI_2071\iq_setup\ IQ_attn.txt) (Figure 1) 註 1: 請依當時 Cable loss 填入: (Ex: IQ_FIX ED_ATTEN_2_4_CHAIN0 = 38.5) (Ex: IQ_FIX ED_ATTEN_2_4_CHAIN1 = 38.5) (Ex: IQ_FIX ED_ATTEN_2_4_CHAIN2 = 38.
WMP-N06 [步驟 2] 測試 Fail (如圖 2), (Figure 2)
