WMP-N06

1.0 Scope

1.1 Document

This document is to specify the product requirements for 802.11b/g MIMO Mini-PCI Card. This MIMO Mini-PCI

Card is based on Atheros AR5008 chipset that complied with 802.11n draft 1.0 standard from 2.4~2.5GHz, and it can

be used to provide up to 11Mbps for IEEE 802.11b and 54Mbps for 2.4GHz IEEE 802.11g to connect your

wireless LAN.

With seamless roaming, fully interoperability and advanced security with WEP standard, 802.11b/g MIMO Mini-

PCI Card offers absolute interoperability with different vendors’ 802.11b/g MIMO Access Points through the

wireless LAN.

1.2 Product Features

 Compatible with IEEE 802.11b high rate standard to provide wireless 11Mbps data rate

 Compatible with IEEE 802.11g higher speed standard to provide wireless 54Mbps data rateo

 Operation at 2.4 ~ 2.5GHz frequency band to meet worldwide regulations

 Dynamic date rate scaling at 6, 9, 12, 18, 24, 36, 48, 54Mbps for 802.11g

 Dynamic date rate scaling at 1, 2, 5.5, and 11Mbps for IEEE 802.11b

 Compatible with IEEE 802.11n draft 1.0 higher speed standard in High Throughput mode from MCS-0 to

MCS-15. The HT data rate refers to Appendix A.

 Maximum reliability, throughput and connectivity with automatic data rate switching

 Supports wireless data encryption with 64/128/152-bit WEP for security

 Supports infrastructure networks via Access Point and ad-hoc network via peer-to-peer communication

 Dual UFL antenna connectors for diversity

 Supports WPA and AES enhanced security

 Supports VLAN tagging

 Friendly user configuration and utilities

 Drivers support Windows 98SE, ME, 2K, and XP

 Supports Mini-PCI Type IIIA form factor

2.0 Requirements

The following sections identify the detailed requirements of the 802.11g/b MIMO Mini-PCI Card.

2.1 General Requirements

2.1.1 IEEE 802.11b Section

# Feature Detailed Description

2.1.1.1 Standard



IEEE 802.11b

2.1.1.2 Radio and

Modulation

Schemes



DQPSK, DBPSK, DSSS, and CCK

2.1.1.3 Operating

Frequency



2400 ~ 2497MHz ISM band

2.1.1.4 Channel Numbers



11 channels for United States

13 channels for Euro

e Countries
