User's Manual
WMP-N06
2.2.2 Configuration
# Feature Detailed Description
2.2.2.1 ESS ID
Input an SSID number if the roaming feature is enabled
Supports for ASCII printable characters.
2.2.2.2 Network Type
Ad-hoc Mode and 802.11 Ad-hoc Mode for network
configurations that do not have any access points
Infrastructure Mode for network configurations with
access points
2.2.2.3 Power Save
Extend the battery life of clients by allowing the client
to sleep for short periods of time while the Access Point
buffers the messages.
2.2.2.4 RTS Threshold
Set the number of bytes used for fragmentation
boundary for messages
2.2.2.5 Fragment
Threshold
Set the number of bytes used for RTS/CTS boundary
2.2.2.6 Transmission Speed
This indicates the communication rates. Select
appropriate transmission speed to match your wireless
LAN settings
2.2.2.7 Roaming
Support Automatic or Manual Rescan to associate with
access point.
2.2.3 Security
# Feature Detailed Description
2.2.3.1 Encryption RC4 encryption algorithm
Support 64/128/152 bit WEP encryption
Support open system and shared key authentication
2.2.3.2 WEP Management Four WEP keys can be selected
STA with WEP off will never associate any AP with
WEP enabled
WEP Key Format: Option for Hex format
2.2.3.3 802.1x
Support EAP-TLS, EAP-TTLS, and EAP-PEAP
2.2.3.4 WPA
Support WPA-PSK and WPA-EAP
Support Cipher Mode AES and TKIP
2.3 Mechanical Requirements
# Feature Detailed Description
2.3.1 Length 50.8mm
2.3.2 Width 59.59mm
2.3.3 Height 0.99mm
2.4 Compatibility Requirements
This device passes the following compatibility requirements.
# Feature Detailed Description
2.4.1 Wi-Fi
Meet Wi-Fi certification for IEEE 802.11 product
2.4.2 WHQL
Meet applicable WHQL certification requirements
2.4.3 Physical Layer and
Functionality
Meet ALPHA Engineering Test Plan and Test Report
2.5 Requirements of Reliability, Maintainability and Quality
# Feature Detailed Description
2.5.1 MTBF
Mean Time Between Failure > 30,000 hours
2.5.2 Maintainability
There is no scheduled preventive maintenance required
