104
745-814-B11-001, Rev. C (03/2014)
13.0 Dual IP Mode (Addendum)
13.5 Security in Dual IP Mode
Method 2: Dual IP Security Using the Secure Access List
The DSM3 provides an alternative method of providing additional SNMP security in Dual IP by limiting
access to the Communications Module’s CPE address. The Secure Access List method limits remote
SNMP access to four IP addresses. Only the IP addresses listed in the SNMP Access Table are able
to read or write to the Alpha MIB parameters from the public (CPE) network. This method overrides the
default Data Access Key method.
The IP address entries in the SNMP Access Table can be set through the DOCSIS Conguration File, the
DSM3 Setup File (atidoc03.cfg) or remotely using SNMP by including the following Alpha MIB parameters:
MIB Parameter Object ID Description Value
atiMgmtSnmpAccessTable 1.3.6.1.4.1.926.1.3.1.2 Table of SNMP
Access Addresses
Object identier
atiMgmtSnmpAccessAddress.1 1.3.6.1.4.1.926.1.3.1.2.1.2.1 SNMP access IP Address #1 0.0.0.0 (Default)
atiMgmtSnmpAccessAddress.2 1.3.6.1.4.1.926.1.3.1.2.1.2.2 SNMP access IP Address #2 0.0.0.0 (Default)
atiMgmtSnmpAccessAddress.3 1.3.6.1.4.1.926.1.3.1.2.1.2.3 SNMP access IP Address #3 0.0.0.0 (Default)
atiMgmtSnmpAccessAddress.4 1.3.6.1.4.1.926.1.3.1.2.1.2.4 SNMP access IP Address #4 0.0.0.0 (Default)
Table 13-7, Secure Access Table Parameters
