20
745-814-B11-001, Rev. C (03/2014)
The DSM3 Series will inherit the cable modem community string settings provided by the DOCSIS
Conguration File.
NOTE:
Table 3-6, Communications Parameters
NOTE:
Before setting options, verify UDP ports 37, 69, 161, 162 and TCP port 80 are not blocked.
SNMP Parameter Type Description Value
atiMgmtSnmpTrapOnNormal
OID: 1.3.6.1.4.1.926.1.3.1.5.1.0
Integer Send SNMP trap when alarmed condition
returns to normal state
1 = Disabled
2 = Enabled (Default)
atiMgmtSysDownloadReCfgTime
OID: 1.3.6.1.4.1.926.1.3.2.1.13.0
Integer Download interval for DSM3 Series-specic
items in atidoc03.cfg cong le (hours)
24 (Default)
atiMgmtSysSnmpTimeout
OID: 1.3.6.1.4.1.926.1.3.1.5.3.0
Integer
Time DSM3 Series will wait before reset if
SNMP trafc is not detected (minutes)
240 (Default)
Note: If set to zero, watchdog will be
disabled.
atiMgmtSysHttpAccess
OID: 1.3.6.1.4.1.926.1.3.2.2.4.1.0
Integer
HTTP Web Server
1 = Disabled
2 = Enabled (default)
See Section 10.0, MIB Parameters for complete parameter denitions.
3.0 Network Conguration
3.4 Setting Communication Options
Communications Settings may be changed through the Alpha MIB remotely using an SNMP MIB browser
or automatically by placing the SNMP parameters into the DOCSIS Conguration File.
See Section 6.0, Data Management for an explanation of the Alpha MIB.
