745-814-B11-001, Rev. C (03/2014)
4.3.1 Web Interface Security Levels
The DSM3 Series Communications Module has two levels of function-specic security. General
operations are Level 1. Conguration-related functions are Level 2. Refer to Table 4-1 for default
User Name and Security Passwords.
Table 4-2, DSM3 Series Communications Module Security Levels
Table 4-1, DSM3 Series Web Page Security
DSM3 Series Web Page Security
OID Function Value
1.3.6.1.4.1.4413.2.2.2.1.1.3.3.0 Level 1 User Name Alpha
1.3.6.1.4.1.4413.2.2.2.1.1.3.4.0 Level 1 Security Password AlphaGet
1.3.6.1.4.1.4413.2.2.2.1.1.3.1.0 Level 2 User Name Alpha
1.3.6.1.4.1.4413.2.2.2.1.1.3.2.0 Level 2 Security Password AlphaSet
Web Page Function Security Level
General
System Name, System Contact, System Location,
Common Logical ID
1
Power Supply Self Test 1
Generator Self Test 1
Advanced Communications
Reset Communications Module 1
Provisioning Mode - Single IP or Dual IP 2
Congure Static IP Address 2
Congure Proprietary Trap Addresses 2
Power Supply Self Test 1
Advanced Power Supply Congure/Save 2
Reset Output 1/2 2
Advanced Generator
Generator Self Test 1
Reset Latched Alarms 1
Modem Log [Event Log] Reset Log 1
Advanced I/O
Tamper Switch Polarity 1
Enclosure Heater/Cooler Installed 1
HMS Alarms Export Alarm Cloning File 2
Apps Overview Congure/Save 2
Battery Management Congure/Save 2
Constellation Number of Samples 2
