6.0 Data Management
6.2.1 SCTE-HMS Congurable Alarms, continued
3. Distribute the “AlarmSettings.acf” le to other DSM3s.
The “AlarmSettings.acf” le is distributed to other DSM3s by setting the following Alpha MIB
parameters to the indicated values. This can be done to an individual DSM3 using a MIB browser,
or to multiple DSM3s by placing the SNMP OIDs into the modem’s DOCSIS conguration le or
the proprietary atidoc03.cfg conguration le.
DSM Alarm Settings Distribution Parameters
Parameter Type Value
atiMgmtSysDownload
OID: 1.3.6.1.4.1.926.1.3.2.1
Object Identier
atiMgmtSysDownloadTftpAddress
OID: 1.3.6.1.4.1.926.1.3.2.1.1.0
IP address The IP address of the TFTP server on which
AlarmSettings.acf is stored.
atiMgmtSysDownloadFile1
OID: 1.3.6.1.4.1.926.1.3.2.1.4.0
Octet String Set to “AlarmSettings.acf” or other specied
le name.
atiMgmtSysDownloadCtrl
OID: 1.3.6.1.4.1.926.1.3.2.1.2.0
Integer 1 = Initiate download of “AlarmSettings.acf”
le.
atiMgmtSysDownloadTftpServerAddressType
OID: 1.3.6.1.4.1.926.1.3.2.1.15.0
Integer Address mode of
atiMgmtSysDownloadTftpServerAddress.
IPv4(1),IPv6(2)
atiMgmtSysDownloadTftpServerAddress
1.3.6.1.4.1.926.1.3.2.1.16.0
Octet String Address of download TFTP server.
0.0.0.0 (IPv4), 0:0:0:0:0:0:0:0 (IPv6)
Parameter Type Value
atiMgmtSysDownloadProgress
OID: 1.3.6.1.4.1.926.1.3.2.1.6.0
Integer Byte count of the le download process.
atiMgmtSysDownloadStatus
OID: 1.3.6.1.4.1.926.1.3.2.1.3.0
Read Only Integer 1 = Idle
5 = Transferring
6 = Testing
8 = Error
The status of the alarm settings download can be monitored with the following parameters
(please note the AlarmSettings.acf le downloads quickly):
Verify the DSM3s’ SCTE-HMS property tables have been updated by viewing the DSM3 HMS
Alarms Web Page, status monitoring system or SNMP MIB browser.
Table 6-5, DSM Alarm Setting Paramters
Table 6-6, Status of Alarm Setting Download Parameters
