73745-814-B11-001, Rev. C (03/2014)
7.0 Installation
atiMgmtSysIoSelect (1.3.6.1.4.1.926.1.3.2.8.1.0)
MIB Value Device Reported Parameter or MIB Branch
1 No device (generic) I/O Pins Only
2 LAP Only atiMgmtSysIoLAPState 1.3.6.1.4.1.926.1.3.2.8.2.0
3 Heater Control Only atiMgmtSysTempMgr * 1.3.6.1.4.1.926.1.3.2.4
4 DC Generator Only atiMgmtSysIoGenState 1.3.6.1.4.1.926.1.3.2.8.3.0
5 Heater Control and LAP atiMgmtSysIoLAPState atiMgmtSysTempMgr *
6 Generator and LAP atiMgmtSysIoLAPState atiMgmtSysIoGenState
*MIBs within atiMgmtSysTempMgr branch will report and control will be allowed regardless of
the value reported by atiMgmtSysIoSelect
Table 7-3, I/O Port Specications
Function Parameter OID Values Description
Input atiMgmtSysIOPinIn4 1.3.6.1.4.1.926.1.3.2.8.21.0 1 = Contact Open
Input atiMgmtSysIOPinIn5 1.3.6.1.4.1.926.1.3.2.8.22.0 1 = Contact Open
2 = Contact Closed
Used to monitor
moisture sensor
Input atiMgmtSysIOPinIn6 1.3.6.1.4.1.926.1.3.2.8.23.0 1 = Contact Open
2 = Contact Closed
Control atiMgmtSysIOPinCtrl 1.3.6.1.4.1.926.1.3.2.8.20.0 1 = Contact Open
2 = Contact Closed
Open/Close a
contact
Alarm/
Trap
IOPinIn4(Open) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.21.0.1
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin4 contact is Open
Alarm/
Trap
IOPinIn4 (Closed) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.21.0.2
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin4 contact is
Closed
Alarm/
Trap
IOPinIn5 (Open) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.22.0.1
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin5 contact is Open
Alarm/
Trap
IOPinIn5 (Closed) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.22.0.2
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin5 contact is
Closed
Alarm/
Trap
IOPinIn6 (Open) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.23.0.1
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin6 contact is Open
Alarm/
Trap
IOPinIn6 (Closed) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.23.0.2
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
Pin6 contact is
Closed
Alarm/
Trap
IOPinCtrl (Open) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6.
1.4.1.926.1.3.2.8.20.0.1
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
control contact is
Open
Alarm/
Trap
IOPinCtrl (Closed) 1.3.6.1.4.1.5591.1.1.3.1.3.13.1.3.6
.1.4.1.926.1.3.2.8.20.0.2
1 = disable
2 = enableMajor
3 = enableMinor
Alarm enable when
control contact is
Closed
7.8.4 I/O Port: Generic Device
The I/O connector on the Alpha DSM3x and DPM allow the headend to remotely monitor and
control external contact relay devices. Each input pin can be congured through the SCTE-HMS
discretePropertyTable for alarm and SNMP trap generation.
Table 7-4, I/O Port: Generic Device Specications
7.8.3 Conguring I/O Port Connections, continued
