10.1 Denitions and Settings
Parameter OID Description Access Type Value
ENVIRONMENTAL I/O CONTROLLER
atiMgmtSysIo 1.3.6.1.4.1.926.1.3.2.8 Object Identier
atiMgmtSysIoSelect 1.3.6.1.4.1.926.1.3.2.8.1 Indicates what function the IO pins are being
used for
Read/Write Integer 1 = Generic
2 = lapOnly
3 = heaterControlOnly
4 = generatorOnly
5 = heaterControlAndLap
6 = generatorAndLap
atiMgmtSysIoLAPState 1.3.6.1.4.1.926.1.3.2.8.2 Current state of the LAP device Read Only Integer 1: notInstalled(1)
2: ok(2)
3: acNotPresent(3)
4: lapBlown(4)
5: lapFail(5)
atiMgmtSysIoGenState 1.3.6.1.4.1.926.1.3.2.8.3 State of the DC Emergency Generator when
sense lines are used
Read Only Integer 1: notInstalled(1)
2: genOff(2)
3: genRunning(3)
4: genNotDetected(4)
5: error(5)
atiMgmtSysIoPinCtrl 1.3.6.1.4.1.926.1.3.2.8.20 Status of the ENV connector Output Pin
(Pin 3)
Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn4 1.3.6.1.4.1.926.1.3.2.8.21 Status of the ENV connector Input Pin#4 Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn5 1.3.6.1.4.1.926.1.3.2.8.22 Status of the ENV connector Input Pin#5 Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn6 1.3.6.1.4.1.926.1.3.2.8.23 Status of the ENV connector Input Pin#6 Read Only Integer 1 = Contact Open
2 = Contact Closed
CABLEWARE MANAGER
atiMgmtSysPhoneHomeIp 1.3.6.1.4.1.926.1.3.2.5 Object Identier
atiMgmtSysPhoneHomeIp 1.3.6.1.4.1.926.1.3.2.5.1.0 Address for the Phone Home Frame Read/Write IP Address 0.0.0.0
atiMgmtSysPhoneHomeForce 1.3.6.1.4.1.926.1.3.2.5.2.0 Forces one Phone Home message
regardless of timers
Read/Write Integer 1=No Operation (default)
2=Force
atiMgmtSysPhoneHomeTimer 1.3.6.1.4.1.926.1.3.2.5.3.0 Time since last frame transmitted, zero
means never transmitted
Read Only Time Ticks
GENERAL CONTROLS
atiMgmtSysTamperPolarity 1.3.6.1.4.1.926.1.3.2.6.1.0 Determines when tamper is active Read/Write Integer 1=doorOpenWhenContactOpen
2=doorOpenWhenContactClosed
(Default)
atiMgmtSysAlphaBusSize 1.3.6.1.4.1.926.1.3.2.6.2.0 Internal microprocessor communications bus
size. Alpha XM3 series power supplies use
9 bit. Alpha GMX and VMX series supplies
use 8 bit
Read/Write Integer 1=9 Bit (default)
2=8 Bit
atiMgmtSysBatteryCalMode 1.3.6.1.4.1.926.1.3.2.6.3.0 This parameter determines which of the
calibration tables to use in cases where the
battery negative is tied to ground or when
it oats.
Read/Write Integer 1=Float
2=Negative
atiMgmtSysAlphaBusSpeed 1.3.6.1.4.1.926.1.3.2.6.4.0 Select the speed at which the AlphaBus will
communicate
Read/Write Integer 1=baud9600
2=baud57600
atiMgmtSysGnrlInfoCongs 1.3.6.1.4.1.926.1.3.2.7.1 Object Identier
atiMgmtSysGnrlInfoCongsMain 1.3.6.1.4.1.926.1.3.2.7.1.1.0 An ASCII string programmed into the main
board non-volatile memory
Read Only Octet String Product number, conguration
number serial number, etc.
atiMgmtSysGnrlInfoCongsDaughter 1.3.6.1.4.1.926.1.3.2.7.1.2.0 An ASCII string programmed into the C/D
battery circuitry (DSM3x only)
Read Only Octet String Product number, conguration
number serial number, etc.
atiMgmtSysGnrlInfoCongsBase 1.3.6.1.4.1.926.1.3.2.7.1.3.0 An ASCII string describing the base
conguration of the device
Read Only Octet String i.e. DSM3, DSM3x
