Manual
Table Of Contents
- Table 1-1, DSM3 Series Model Specifications
- Table 2-1, LEDs and Indications
- Table 3-1, Modem Community String Parameters — DOCSIS 2.0 (IPv4) Method
- Table 3-2, Modem Community String Parameters — DOCSIS 2.0+IPv6 Method
- Table 3-3, Trap Destination Addresses — DOCSIS 2.0 (IPv4) Method
- Table 3-4, Trap Destination Addresses — DOCSIS 2.0+IPv6 Method
- Table 3-5, Default atidoc.cfg Download Settings
- Table 3-6, Communications Parameters
- Table 4-1, DSM3 Series Communications Module Security Levels
- Table 4-3, Time Offset Values and Location Reference (offset +/- GMT)
- Table 5-1, Modem Firmware Upgrade SNMP Parameters
- Table 5-2, SNMP Parameters
- Table 5-3, DOCSIS Configurations File Values
- Table 6-1, SCTE-HMS MIB Files
- Table 6-2, Binary to Hex Conversions for Alarm Settings
- Table 6-3, Recommended Settings for DSM3 Series Analog Alarms
- Table 6-4, Recommended Settings for Discrete Alarms
- Table 6-5, DSM Alarm Setting Paramters
- Table 6-6, Status of Alarm Setting Download Parameters
- Table 6-7, SNMP Alarm Trap Varbinds and Explanations
- Table 6-8, Power Alarms: Classifications, Causes and Corrections
- Table 6-9, Battery Alarms: Classifications, Causes and Corrections
- Table 6-9, Alpha MIB Hierarchy
- Table 6-10, Alpha MIBs Examples
- Table 7-1, Tamper (TPR) Switch Specifications
- Table 7-2, ENV Connector and Pin Descriptions
- Table 7-3, I/O Port Specifications
- Table 7-4, I/O Port: Generic Device Specifications
- Table 7-5, LA-P-SM Monitoring Values
- Table 7-6, I/O Port: Heater Mat Control Specifications
- Table 7-7, Heater Mat OIDs and Functionality
- Table 7-8, Heater Mat MIB Reports
- Table 7-9, Generator Monitoring Values
- Table 9-1,SCTE-HMS Property Table
- Table 9-2, Rx/Tx Power LED Color Ranges
- Table 13-1, Single IP Mode versus Dual IP Mode
- Table 13-2, Enabling Dual IP mode
- Table 13-3, CPE Communications Module IP Settings
- Table 13-4, Available Download Options
- 1.0 Introduction
- 2.0 Overview
- 3.0 Network Configuration
- 3.1 Provisioning the DHCP Server with the MAC Addresses
- 3.2 Establishing IP Connectivity
- 3.3 The DOCSIS Configuration File
- 3.3.8 Changing Default atidoc03.cfg Download Settings
- 3.3.7 Proprietary Configuration File ‘atidoc03.cfg’
- 3.3.6 Sample DOCSIS Configuration File Entries — DOCSIS 2.0+IPv6
- 3.3.5 Sample DOCSIS Configuration File Entries — DOCSIS 2.0 (IPv4)
- 3.3.4 Setting SNMP Trap Destination Addresses — DOCSIS 2.0+IPv6 Method
- 3.3.3 Setting SNMP Trap Destination Addresses — DOCSIS 2.0 (IPv4) Method
- 3.3.2 Setting Modem Community Strings — DOCSIS 2.0+IPv6 Method
- 3.4 Setting Communication Options
- 4.0 Web Interface
- 4.1 Local Web Server Access
- 4.2 Remote Web Server Access
- 4.3 Navigating the Web Page
- 4.4 Verifying Communication Parameters
- 4.5 Verifying Power Supply and Battery Parameters
- 4.6 Remote Self Tests via the Web Page
- 4.7 Viewing HMS Alarm Status via the Web Page
- 4.8 Setting the I/O Controller via the Web Page
- 4.9 Viewing and Configuring Power Supply settings via the Web Page
- 4.10 Viewing and Configuring Generator Settings via the Web Page
- 4.11 Tools Menu – Constellation and Microreflections
- 4.12 Viewing AlphaApps Information via the Web Page
- 4.13 Battery Management
- 4.14 Viewing Power Supply Event and Configuration Logs
- 4.15 Battery Event Log
- 4.16 Viewing the Modem Event Log via the Web Page
- 5.0 Upgrading Firmware
- 6.0 Data Management
- 7.0 Installation
- 7.1 Verifying Power Supply Device Address
- 7.2 Installation / Replacement Procedure in XM3 Power Supplies
- 7.3 DSM3x LEDs and Connections
- 7.4 DSM3 LEDs and Connections
- 7.5 DPM LEDs and Connections
- 7.6 Connecting the RF Drop
- 7.7 Front Panel Connections
- 7.8 I/O Connections (TPR, ENV)
- 7.8.1 Tamper (TPR) Switch Interface
- 7.8.2 I/O Port Interface
- 7.8.3 Configuring I/O Port Connections
- 7.8.4 I/O Port: Generic Device
- 7.8.5 Connecting a Generic I/O Device
- 7.8.6 Configuring and Monitoring a Generic I/O Device
- 7.8.7 I/O Port: Lightning Arrestor (LA-P-SM)
- 7.8.8 Lightning Arrestor (LA-P-SM) Installation
- 7.8.9 Configuring the LA-P-SM
- 7.8.10 I/O Port: Heater Mat Control
- 7.8.11 Connecting the Battery Heater Mat Controller, continued
- 7.8.12 Configuring the Battery Heater Mat Controller
- 7.8.14 Configuring and Monitoring the DC Emergency Generator
- 8.0 Battery Sense Wire Kits
- 9.0 Start Up and Verification
- 10.0 Alpha MIB Parameters
- 11.0 Specifications
- 12.0 Glossary
- 13.0 Dual IP Mode (Addendum)
- 13.1 Overview
- 13.2 Web Comparison, Single IP Mode/Dual IP Mode
- 13.3 Configuring Dual IP Mode
- 13.3.3 Specifying atidoc03.cfg name and location via DHCP Tags
- 13.3.2 Changing Default atidoc03.cfg Download Settings in Dual IP Mode
- 13.3.1 atidoc03.cfg in Dual IP Mode
- 13.4 Dual IP SNMP Community Strings
- 13.5 Security in Dual IP Mode
- Fig. 1-1, AlphaNet DSM3x
- Fig. 1-2, AlphaNet DSM3
- Fig. 1-3, AlphaNet DPM
- Fig. 1-4, Side view, AlphaNet DSM3 Series
- Fig. 2-1, Representative System Arrangement
- Fig. 3-1, Locations of MAC Address Labels
- Fig. 3-2, Sample DOCSIS Configuration File — DOCSIS 2.0 (IPv4)
- Fig. 3-3, Sample DOCSIS Configuration File — DOCSIS 2.0+IPv6
- Fig. 4-1, DSM3 Series Web Page
- Fig. 4-2, Local Area Connection Properties Screen, Windows XP
- Fig. 4-3, Internet Protocol (TCP/IP) Properties Screen, Windows XP
- Fig. 4-4, Local Area Connection Properties Screen, Windows 7
- Fig. 4-5, Internet Protocol (TCP/IP) Properties Screen, Windows 7
- Fig. 4-6, Web Server Home Page
- Fig. 4-7, DSM3 Series Navigation Bar Items
- Fig. 4-8, Communication Parameters
- Fig. 4-9, Advanced Communication Parameters
- Fig. 4-10, Power Supply and Battery Parameters
- Fig. 4-11, Location of Start Test Button for Self Test
- Fig. 4-12, HMS Alarm Configuration
- Fig. 4-13, Advanced I/O Controller Status Screen
- Fig. 4-14, Advanced Power Supply Settings Screen
- Fig. 4-15, Advanced Generator Status Screen
- Fig. 4-16, QAM Constellation Tool
- Fig. 4-17, Normal - (Good Quality) and Individual Cell Characteristics
- Fig. 4-18, Fuzzy (Low CNR and/or Low MER) and Individual Cell Characteristics
- Fig. 4-19, Doughnuts (Coherent Interference) and Individual Cell Characteristics
- Fig. 4-20, Gaussian Noise and Individual Cell Characteristics
- Fig. 4-21, Rectangular vs. Square (I-Q Imbalance) and Entire Constellation Shape
- Fig. 4-22, Corners Squeezed to Center (Gain Compression) and Entire Constellation Shape
- Fig. 4-23, Circular Smear (Phase Noise) and Entire Constellation Shape
- Fig. 4-24, Twisted or Skewed (Quadrature Distortion) and Entire Constellation Shape
- Fig. 4-25, Microreflections Tool
- Fig. 4-26, Alpha Apps and Utility Status Parameters
- Fig. 4-27, Battery Management
- Fig. 4-28, Battery Model Selection
- Fig. 4-29, DSM3 System Log
- Fig. 4-30, Power Supply Event Log
- Fig. 4-31, Power Supply Configuration Log
- Fig. 4-33, Docsdev Event Log Screen
- Fig. 6-1, Sample Raw SNMP Alarm Trap
- Fig. 6-2, Sample Translated SNMP Alarm Trap
- Fig. 7-1, Captive Screw Locations
- Fig. 7-3, Connecting the Communications Module to the Inverter Module
- Fig. 7-2, The 18-pin Connector
- Fig. 7-4, DSM3x LEDs and Connectors
- Fig. 7-5, DSM3 LEDs and Connectors
- Fig. 7-6, DPM LEDs and Connectors
- Fig. 7-7, Connecting the RF Drop
- Fig. 7-8, System Interconnection Diagram
- Fig. 7-9, I/O (ENV) and Tamper Switch Interface (TPR) Connection Locations
- Fig. 8-1, 36V System, Single String
- Fig. 8-2, 36V System, Dual String
- Fig. 9-1, XM3 Smart Display Screens
- Fig. 9-2, Communications Section - General Page
- Fig. 9-3, Power Supply Section - General Page
- Fig. 9-4, LED Functionality and Indications
- Fig. 9-5, DSM3 Series Web Page, RF Power Level Indicators
- Fig. 13-1, Simplified Block Diagram Single IP Mode
- Fig 13-2, Simplified Block Diagram Dual IP Mode
- Fig. 13-3, Single IP DSM3 Series Web Page
- Fig. 13-4, Dual IP DSM3 Series Web Page
- Fig. 13-5, Dual IP Configuration Settings for DSM3 Web Server Communications Page
- Fig. 13-6, Dual IP Parameters for DSM3 Web Server General Page
91745-814-B11-001, Rev. C (03/2014)
Parameter OID Description Access Type Value
SCALARS
atiBBSysViewScalars 1.3.6.1.4.1.926.1.4.1.1.3 Object Identier
atiBBSysViewInputVoltage 1.3.6.1.4.1.926.1.4.1.1.3.1.0 Power supply input voltage Read Only Integer
atiBBSysViewInputFrequency 1.3.6.1.4.1.926.1.4.1.1.3.2.0 Power supply input line frequency Read Only Integer
atiBBSysViewInputCurrent 1.3.6.1.4.1.926.1.4.1.1.3.3.0 Power supply input current Read Only Integer
atiBBSysViewBatteryVoltage 1.3.6.1.4.1.926.1.4.1.1.3.4.0 Battery voltage Read Only Integer
atiBBSysViewBatteryTemperature 1.3.6.1.4.1.926.1.4.1.1.3.5.0 Battery temperature (Degrees C) Read Only Integer
atiBBSysViewChargerCurrent 1.3.6.1.4.1.926.1.4.1.1.3.6.0 Sum of charging current from all power supplies Read Only Integer
atiBBSysViewChargerVoltsFloat 1.3.6.1.4.1.926.1.4.1.1.3.7.0 Battery charger oat voltage Read/Write Integer
atiBBSysViewChargerVoltsEqualize 1.3.6.1.4.1.926.1.4.1.1.3.8.0 Battery charger equalization voltage Read/Write Integer
atiBBSysViewChargerVoltsTemperatureComp 1.3.6.1.4.1.926.1.4.1.1.3.9.0 Battery charger temperature compensation
(0 to 5mV/Cell/°C)
Read/Write Integer
atiBBSysViewBatteryCapacity 1.3.6.1.4.1.926.1.4.1.1.3.10.0 Battery string capacity (Amp hours) Read/Write Integer
DETECT 6V BATTS
atiCibDiscTable 1.3.6.1.4.1.926.1.2.1.1.1.5.
14.0.11
Controls the ability to detect and report 6 Volt
batteries
Read/Write Integer 0 = default
1 = Detect 6 Volt
Batteries
SYSTEM COUNTERS
atiBBSysViewCounters 1.3.6.1.4.1.926.1.4.1.1.4 Object Identier
atiBBSysViewSelfTestInterval 1.3.6.1.4.1.926.1.4.1.1.4.1.0 Power supply Self Test interval Read/Write Integer
atiBBSysViewSelfTestCountdown 1.3.6.1.4.1.926.1.4.1.1.4.2.0 Power supply Self Test countdown Read/Write Integer
atiBBSysViewSelfTestDuration 1.3.6.1.4.1.926.1.4.1.1.4.3.0 Power supply Self Test duration Read/Write Integer
atiBBSysViewInverterRuntime 1.3.6.1.4.1.926.1.4.1.1.4.4.0 Power supply inverter runtime Read Only Integer
atiBBSysViewStandbyEvents 1.3.6.1.4.1.926.1.4.1.1.4.5.0 Power supply standby events Read Only Integer
atiBBSysViewRuntimeRemaining 1.3.6.1.4.1.926.1.4.1.1.4.6.0 Power supply runtime remaining Read Only Integer
atiBBSysViewTimeInStandby 1.3.6.1.4.1.926.1.4.1.1.4.7.0 Power supply time in standby Read Only Integer
atiBBSysViewTimeSinceLastStandby 1.3.6.1.4.1.926.1.4.1.1.4.8.0 Power supply time since last standby Read Only Integer
SYSTEM LOGS
atiBBSysLogs 1.3.6.1.4.1.926.1.4.1.2 Object Identier
atiBBSysLogsEventsTable 1.3.6.1.4.1.926.1.4.1.2.1 Table of logged events Read Only
atiBBSysLogsCongTable 1.3.6.1.4.1.926.1.4.1.2.2 Table of logged conguration items Read Only
atiBBSysLogsPerformTable 1.3.6.1.4.1.926.1.4.1.2.3 Table of logged performance information Read Only
atiBBSysLogsBatteryTable 1.3.6.1.4.1.926.1.4.1.2.4 Table of logged battery information Read Only
SYSTEM APPLICATIONS
atiBBSysApps 1.3.6.1.4.1.926.1.4.1.3 Object Identier
atiBBSysAppsPsHealth 1.3.6.1.4.1.926.1.4.1.3.1 Object Identier
atiBBSysAppsPsHealthPsCount 1.3.6.1.4.1.926.1.4.1.3.1.1.0
Indicates the number of power supplies that support
health analysis
Read Only Integer
atiBBSysAppsPsHealthTable 1.3.6.1.4.1.926.1.4.1.3.1.2 Table - row for each power supply
atiBBSysAppsBattStatus 1.3.6.1.4.1.926.1.4.1.3.2 Object Identier
atiBBSysAppsBattTable 1.3.6.1.4.1.926.1.4.1.3.2.1 Table - row for each battery Read Only Integer
atiBBSysAppsBattStringNum 1.3.6.1.4.1.926.1.4.1.3.2.1.1.1 String that this battery is a member of Read Only Integer 1 to 4
atiBBSysAppsBattBatteryNum 1.3.6.1.4.1.926.1.4.1.3.2.1.1.2 Battery number in string Read Only Integer 1 to 4
atiBBSysAppsBattMfgDate 1.3.6.1.4.1.926.1.4.1.3.2.1.1.3 Manufacture Date, typically stamped onto battery Read/Write Octet String Date
atiBBSysAppsBattAge 1.3.6.1.4.1.926.1.4.1.3.2.1.1.4 Age of battery in months based on Manufacture Date Read Only Integer
atiBBSysAppsBattMhos 1.3.6.1.4.1.926.1.4.1.3.2.1.1.5 Measured Battery MHOs Read/Write Integer
10.1 Denitions and Settings
10.0 Alpha MIB Parameters
