92
745-814-B11-001, Rev. C (03/2014)
10.1 Denitions and Settings
10.0 Alpha MIB Parameters
Parameter OID Description Access Type Value
SYSTEM APPLICATIONS
atiBBSysAppsBattBalancing 1.3.6.1.4.1.926.1.4.1.3.2.1.1.6 Status of attempt to balance the battery Read Only Integer
1=balanced
2=inProgess
3=failed
atiBBSysAppsBattStringCount 1.3.6.1.4.1.926.1.4.1.3.2.2.0
Indicates the number of batteries that support
Health Analysis
Read Only Integer
atiBBSysAppsBattPerStringCount 1.3.6.1.4.1.926.1.4.1.3.2.3.0
Indicates the number of batteries that support
Health Analysis
Read Only Integer
atiBBSysAppsBattConductanceMeasurementDate 1.3.6.1.4.1.926.1.4.1.3.2.4.0 Date of last conductance measurement Read Only Octet String Date and Time
atiBBSysAppsBattStandbyTimeRemaining 1.3.6.1.4.1.926.1.4.1.3.2.5.0
Remaining runtime if batteries are currently
discharging or available runtime for next discharge
Read Only Integer
1=overThreeHr
2=twoToThreeHr
3=oneToTwoHr
4=lessThanOneHr
5=calculating
6=notAvailable
atiBBSysAppsBattLifeRemaining 1.3.6.1.4.1.926.1.4.1.3.2.6.0 Remaining time before batteries need to be replaced Read Only Integer
1=overFiveYr
2=threeToFiveYr
3=twoToThreeYr
4=lessThanTwoYr
5=pmRecomnded
6=notAvailable
atiBBSysAppsUtilQualSupported 1.3.6.1.4.1.926.1.4.1.3.3.1.0 Indicates if Utility Quality Analysis is supported Read Only Integer
1=unsupported
2=supported
atiBBSysAppsUtilQualStartDate 1.3.6.1.4.1.926.1.4.1.3.3.2.0 Date upon which Utility Analysis started Read Only Octet String Date
atiBBSysAppsUtilQualStatus 1.3.6.1.4.1.926.1.4.1.3.3.3.0 Indicates the current line status Read Only Integer
1=ok
2=outage
3=sag
4=surge
5=frequency
6=unknown
atiBBSysAppsUtilQualSag 1.3.6.1.4.1.926.1.4.1.3.3.4 Object Identier
atiBBSysAppsUtilQualSagCurDuration 1.3.6.1.4.1.926.1.4.1.3.3.4.1.0 Time duration of current Sag event Read Only Time Ticks
atiBBSysAppsUtilQualSag24HourCount 1.3.6.1.4.1.926.1.4.1.3.3.4.2.0 Number of Sag events in the last 24 hours Read Only Integer
atiBBSysAppsUtilQualSag24HourAvgDuration 1.3.6.1.4.1.926.1.4.1.3.3.4.3.0
Average duration of Sag events occurring in the
last 24 hours
Read Only Time Ticks
atiBBSysAppsUtilQualSag24HourMinDuration 1.3.6.1.4.1.926.1.4.1.3.3.4.4.0
Minimum duration of Sag events occurring in the
last 24 hours
Read Only Time Ticks
atiBBSysAppsUtilQualSag24HourMaxDuration 1.3.6.1.4.1.926.1.4.1.3.3.4.5.0
Maximum duration of Sag events occurring in the
last 24 hours
Read Only Time Ticks
atiBBSysAppsUtilQualSagLifetimeCount 1.3.6.1.4.1.926.1.4.1.3.3.4.6.0 Number of Sag events since device initialized Read Only Integer
atiBBSysAppsUtilQualSagLifetimeDurationSum 1.3.6.1.4.1.926.1.4.1.3.3.4.7.0
Total accumulated time in Sag since device
initialized
Read Only Time Ticks
atiBBSysAppsUtilQualSagLifetimeMaxDuration 1.3.6.1.4.1.926.1.4.1.3.3.4.8.0 Time of longest Sag since device initialized Read Only Time Ticks
atiBBSysAppsUtilQualSurge 1.3.6.1.4.1.926.1.4.1.3.3.5 Object Identier
atiBBSysAppsUtilQualSurgeCurDuration 1.3.6.1.4.1.926.1.4.1.3.3.5.1.0 Time duration of current Surge event Read Only Time Ticks
atiBBSysAppsUtilQualSurge24HourCount 1.3.6.1.4.1.926.1.4.1.3.3.5.2.0 Number of Surge events in the last 24 hours Read Only Integer
