Installation guide

Welcome
Congratulations on purchasing the door phone panel Fermax IP DP “VoIP
Door Phone”, which is a SIP based VoIP version of "Fermax PBX DP" analog
door phone panel. This door phone can satisfy your need of communication
with visitors at the entrance to the building, to your company or at the entrance
of your house. VoIP means “Voice over Internet Protocol” – the door phone
is connected to the computer network and enables both P2P (peer to peer)
connection – i.e. it calls to an IP address of other VoIP device directly or it is
registered to a SIP server, then it calls a phone number. There can be
assigned up to two 25 digit numbers including characters “* ”, “ # ” .
The basic module of the door phone always contains 2 pushbuttons and
optionally the first expansion, 8 pushbutton C module. The combination of
Fermax New Cityline panels enable the sets of door phone with 1 to 10
pushbuttons just by using the basic electronics module of Fermax IP DP. You
can also expand the whole system by the 8 pushbutton expansion module
Fermax PBX EXP up to the limit of 64 pushbuttons. The basic module can
contain a colour camera, optionally there can be an add-on speaker module
with an amplifier Fermax PBX EA, which is used for very noisy areas. The
Fermax New Cityline panels are rich with an add ons. For example the panels
offer installations on the surface or flush mounted, they can be used both
indoors and outdoors, there can be add-on roofing used, etc.
The Fermax IP DP door phone panel is powered by 12V of the power
supply, which can also be used for powering the electrical lock of the door. The
Fermax IP DP is also PoE powered (Power over Ethernet). The features of the
door phone are similar to a hands-free telephone. Among basic features you
can find the possibility of opening up to two doors via connected electrical locks
and also an easy WEB based programming.
Manual version V3.1 8-4-2010
Valid for firmware of the VoIP module - V1.35
The producer improves the SW (firmware) of the door phone panel
continuously. Fermax IP DP panel enables uploading the latest firmware
version via a standard PC. The latest firmware can be downloaded at
http://www.alphatech.cz/ipdp-firmware/firmware.htm.
All necessary steps for this process can be found on page 30. We strongly
recommend using the latest firmware version, which brings new features and
solves various possible issues of the continuosly improving Fermax door
phone panel. At www.alphatech.cz you can also find the latest version of
user and installation guide.
