Jeep

SUV  1/14

HCE-TCAM1-WRA

Spare Tire Camera &

Light System

for Jeep Wrangler

Installation Manual



Model: Jeep Wrangler (JK)



Model Year: 2007-UP

* The speciﬁ ed vehicles have been tested and have met compatibility speciﬁ cations at the time

of testing. Compatibility is not guaranteed if the manufacturer has made production changes

to the vehicles listed above.

Introductions

 Design and speciﬁ cations are subject to change without notice for improvement.

To Ensure Safe Use, Always Follow These Precautions

 The installation of this product requires specialized skills and experience. We recommend that you have the

product installed by an Alpine authorized dealer.

 Before you use this product, be sure to carefully read this installation manual and the separate user’s manual

so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as

a result of failure to follow the instructions in the manuals.

 This manual includes a number of symbols that are intended to help you use the product safely, to prevent

harm to you and others, and to protect against damage to property. These symbols and their meanings are

listed below. Make sure you fully understand these symbols before you begin reading the main text.

Explanations of Injury and Damage That May Result from Incorrect Use

Warning

Ignoring the content marked by this indication and using the product incorrectly is

expected to lead to death or serious injury.

Caution

Ignoring the content marked by this indication and using the product incorrectly is only

expected to lead to injury or property damage.

336034 HCE-TCAM1-WRA_IM_r5.indd 1336034 HCE-TCAM1-WRA_IM_r5.indd 1 7/20/16 4:02 PM7/20/16 4:02 PM

Summary of content (14 pages)

PAGE 1
Jeep SUV 1/14 HCE-TCAM1-WRA Spare Tire Camera & Light System for Jeep Wrangler Installation Manual Model: Jeep Wrangler (JK) Model Year: 2007-UP * The speciﬁed vehicles have been tested and have met compatibility speciﬁcations at the time of testing. Compatibility is not guaranteed if the manufacturer has made production changes to the vehicles listed above. Introductions Design and speciﬁcations are subject to change without notice for improvement.
PAGE 2
Spare Tire Camera & Light System for Jeep Wrangler 2/14 Warning Types of Precautions Indicates actions that are forbidden (must not be performed) Indicates actions that are mandatory (must be performed) Mandatory Forbidden Indicates that disassembly is forbidden. Marks content that should receive your full attention. Forbidden Warning Do not disassemble or modify the product. Doing so could lead to an accident, fire, or electric shock.
PAGE 3
Spare Tire Camera & Light System for Jeep Wrangler 3/14 Warning When making a hole in the vehicle body, be careful to avoid damaging pipes, the fuel tank, electrical wiring, and the like. This kind of damage could lead to an accident or fire. When installing and grounding the product, do not use any of the bolts or nuts of the steering wheel, brakes, fuel tank, or the like. Doing so could make the brakes stop working or lead to fire.
PAGE 4
Spare Tire Camera & Light System for Jeep Wrangler 4/14 Installation Kit Parts Accessory List Spare Tire Camera & Light Unit Mounting Base Lug Nut Camera Base Mounting Posts (Short, Mid, Long) M4 Hex Socket Cap Screws (8pcs) Camera & Light Extension Cable (7m) Rubber Grommet Installation Manual Warranty Card and Quick Start Guide Camera & Light T-Harness 336034 HCE-TCAM1-WRA_IM_r5.
PAGE 5
Spare Tire Camera & Light System for Jeep Wrangler 5/14 Tools Required Panel Removing Tool Pliers T25 Torx #2 Phillips Screwdriver Wire Cutters Torque Wrench 10 mm Sockets Socket Extension 19 mm Deep Socket 336034 HCE-TCAM1-WRA_IM_r5.
PAGE 6
Spare Tire Camera & Light System for Jeep Wrangler 6/14 Spare Tire Camera and Light Installation Glove Box Removal Removing B-Pillar Panel 1 2 1 Remove B-Pillar panel by disengaging 4 clips on both front and rear passenger sides. 2 Using panel removing tool, unclip the B-Pillar. Be careful not to damage the panel. 3 Lift the carpet up on both front and rear passenger sides to expose the OEM cables. Open the glove box. Push inwards both left and right sides to release the glove box out.
PAGE 7
Spare Tire Camera & Light System for Jeep Wrangler 7/14 Spare Tire Camera and Light Installation Removing Rear Right Side Panel 1 2 3 Using 10mm socket to remove the panel. 4 Unclip the cigarette lighter socket from the harness. 5 Remove the Rear Right Side Panel. Using T25 Torx, remove the screws on the rear right side panel. Using panel removing tools, pry off seatbelt cover[#1] and remove the roll cage cover[#2]. 1 2 336034 HCE-TCAM1-WRA_IM_r5.
PAGE 8
Spare Tire Camera & Light System for Jeep Wrangler 8/14 Spare Tire Camera and Light Installation Spare Tire and Wheel Removal Camera & Light Extension Cable Installation 1 2 1 Using 19mm socket, extract the lug nuts. Remove the spare tire center cap. Pop center cap out Connection Type Connectable Head Unit A Direct Connection X109-WRA B Using Camera T-Harness Connection i109-WRA C 3 Using panel removing tools, unclip and remove wire cover on the rear gate.
PAGE 9
Spare Tire Camera & Light System for Jeep Wrangler 9/14 Spare Tire Camera and Light Installation - Connection Type C – If connecting to all other HU, cut Camera & Light T-Harness and manually connect to each wire located on the passenger’s kick panel, then connect 6pin black connector to gray connector on the Camera & Light Extension Cable. (See page 14 in detail) G. Secure to the factory cables. Connect ACC and GND properly according to the wiring diagram in page 14.
PAGE 10
Spare Tire Camera & Light System for Jeep Wrangler Spare Tire Camera and Light Installation 10/14 OPTION 2: H. Route the wire out of a rear gate vent behind tire carrier. I. Along and through the centric hub. 336034 HCE-TCAM1-WRA_IM_r5.
PAGE 11
Spare Tire Camera & Light System for Jeep Wrangler 11/14 Spare Tire Camera and Light Installation Spare Tire Camera & Light Unit Installation 1 Choose the length of the mounting post (Short, Mid, Long) based on your wheel depth and offset in order to see entire camera view. DEEP MID SHALLOW WHEEL TYPE CROSS SECTION SHORT MID LONG Camera View Camera View Camera View Do not block downward view by wheel or tire. Post Type Long Mid Short Length 4-1/4 inch (108.0mm) 3.0 inch (76.
PAGE 12
Spare Tire Camera & Light System for Jeep Wrangler 12/14 2 Using M4 hex key, assemble the lug nut camera base, mounting post, mounting base with the harness running along the cutout and inside the post. 3 Position the mounting base assembly over the factory lug nuts. Ensure that no wires are pinched or interfered with any parts or safety equipment. 4 Mount the spare tire back on the hub. Make sure the mount is aligned correctly and connector coming out of the center cap hole.
PAGE 13
Spare Tire Camera & Light System for Jeep Wrangler 13/14 5 6 Connect the Spare Tire Camera and Light unit. Completed Installation Image Do not drop Spare Tire Camera & Light unit on hard surface. Doing so could damage the unit. 1 Reinstall all panels, covers, carpets, cigarette lighter socket, and glove box as it was taken out. Place ﬂoor mat or carpet on the ground underneath the camera to protect Spare Tire Camera & Light unit from dropping.
PAGE 14
Spare Tire Camera & Light System for Jeep Wrangler 14/14 Wiring Diagram Connection Type A Direct Connection Main Harness (Refer to X109-WRA Installation Manual Page 11: Wiring Diagram) MANUAL TRANSMISSION VEHICLES To HCE-TCAM1-WRA Rear View Camera X109D - DVD/Display White/Gray Manual Transmission Reverse Input For manual transmission vehicles ONLY. Connect the White/Gray wire to the White/Gray wire located on the passenger side kick panel.
