Installation Instructions User Manual

- 2 - M series
Overview:
These multi-output access control power supply/chargers are specifically designed for use with access control systems and
accessories. These units convert a 115VAC, 60Hz input into five (5) individually protected 12VDC or 24VDC outputs (see
specifications). Each output will route power to a variety of access control hardware devices including Mag Locks, Electric
Strikes, Magnetic Door Holders, etc. These outputs will operate in both Fail-Safe and Fail-Secure modes. Controlled
trigger input is achieved through normally open [NO] or normally closed [NC] supervised input or the polarity reversal
from an FACP (Fire Alarm Control Panel). A form “C” dry output relay enables HVAC Shutdown, Elevator Recall or may
be used to trigger auxiliary devices.
M Series Power Supply Configuration Reference Chart:
Altronix
Model
Number 12VDC Total Output Current (amp) 24VDC Total Output Current (amp) Outputs Class 2 Rated Power Limited 115VAC 60Hz Input (current draw/amp) Individual Output Rating (amp) Power Supply Board Input Fuse Rating Power Supply Board Output Fuse Rating Agency Listings UL Listings and File Numbers
AL300ULM
2.5 2.5 5 Yes 3.5 amp 2
5A/
250V
15A/
32V
UL 294
UL Listed Access Control System Unit.
UL 603
UL Listed for Burglar Alarms Systems.
UL 1069
UL Listed Hospital Signaling and
Nurse Call Equipment.
UL 1481
UL Listed for Power Supplies for
Fire Protective Signaling Systems
AL400ULM
4 3 5 Yes 3.5 amp 2
5A/
250V
15A/
32V
AL600ULM
6 6 5 Yes 3.5 amp 2
5A/
250V
-------------
AL1012ULM
10 ------------ 5 Yes 2.6 amp 2
5A/
250V
15A/
32V
UL File # BP617
UL 294
UL Listed Access Control System Unit.
AL1024ULM
------------ 10 5 Yes 4.2 amp
2
5A/
250V
15A/
32V
UL 294
UL Listed Access Control System Unit.
UL 1481
UL Listed for Power Supplies for
Fire Protective Signaling Systems
Specifications:
Input:
• Powerinput115VAC60Hz(seereferencechartabove).
• FireAlarmPanelorAccessControlSystemtrigger  
inputs. [NO] or [NC] supervised trigger input and
polarity reversal trigger input (4mA draw from FACP).
Output:
• Five(5)individualpowerlimitedclass2outputs.
• Currentlimitis2amp@12VDCor24VDC
per output (12VDC only for AL1012ULM,
24VDC only for AL1024ULM).
Burglar Alarm Applications (UL 603)
AL300ULM and AL400ULM only:
12VDC = 10VDC-13.2VDC.
24VDC = 20VDC-26.4VDC.
• Filteredandelectronicallyregulatedoutputs.
• Thermalandshortcircuitprotectionwithautoreset.
• Overloadprotection.
• Outputrelayenergizeswhenunitistriggered
 (form“C”contactrated1amp@28VDC).
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
• Automaticswitchovertostand-bybatterywhenACfails.
Battery Backup (cont’d):
•Zerovoltagedropwhenswitchingoverto
battery backup.
• AL300ULM,AL400ULM,AL600ULMand
AL1012ULM (Power Supply Board) maximum
charge current 0.7 amp.
AL1024ULM (Power Supply Board) maximum
charge current 3.6 amp.
• AL300ULM,AL400ULMandAL600ULMenclosures
accommodate up to two (2) 12VDC/7AH batteries.
• AL1012ULMshouldbefittedwith
one (1) 12VDC/12AH battery.
• AL1024ULMshouldbefittedwith
two (2) 12VDC/12AH batteries.
Visual Indicators:
• DCoutputLEDindicator.
• LEDsindicateconditionofpoweroutputs.
• Power&inputtriggerLED’s.
Supervision:
• ACfailsupervision(form“C”contact).
• Lowbatterysupervision(form“C”contact).
• Batterypresencesupervision(form“C”contact).
