K-KT914Z - Kona INSTRUCTION MANUAL FRAMELESS BATHTUB ENCLOSURE KK019
IN LINE GLASS SLIDING SHOWER DOOR Please keep this manual and product code number for future reference and replacement parts ordering if necessary.
IN LINE GLASS SLIDING SHOWER DOOR INSTALLATION INSTRUCTIONS FOR CURVED GLASS SLIDING SHOWER DOOR Congratulations! You have made the right choice in buying the shower system. We are convinced that you will be entirely satisfied with our product.
REQUIRED TOOLS LIST 1/4” 1/8” DRILL BIT CERAMIC TILE DRILL BIT SCREWDRIVERS 5/16’’ SILICON DRILL LEVEL HEX NUT DRIVER PENCIL MEASURE TAPE MALLET PACKAGING CHECK LIST & HARDWARE 5 4 8 OR 10 (FOR ‘’PARIS POINT ’’ GLASS ONLY) SET OF HANDLES (2) SIDE GASKET (4) 12 11 SIDE GASKET (2) 13 MAGNETIC DOOR GASKET (2) 14 (M4 X 8) BOTTOM SLIDER SHIM (4) GLASS SUPPORT (8) 16 15 SCREW 1 3/8” LG (14) SCREW 3/8” LG (8) 18 17 (M4 X 35) SCREW CAP (8) WALL PLUG (8) (M4 X 8) SCREW ½” LG (8)
IN LINE GLASS SLIDING SHOWER DOOR 8 9 6 5 4 11 3 2 10 1 7 1 2 3 WALL JAMB (2) 4 EXPANDER (2) 5 FIXED PANEL (2) 6 7 SET OF HANDLES (2) SIDE GASKET (4) DOOR PANEL ASSEMBLY (2) BOTTOM TRACK (1) 8 9 10 11 SIDE GASKET WALL JAMB SIDE (2) TOP TRACK (1) MAGNETIC DOOR GASKET (2) GLASS SUPPORT (8) PAGE 1
DOOR INSTALLATION STEPS TOP TRACK (1) BOTTOM TRACK (1) Step 1 EXPENDER (2) + TRACK (2) + SCREW 1 3/8’’ LG (8) Step 2 INSERT WALL JAMBS PAGE 3
DOOR INSTALLATION STEPS Step 3 POSITION AND CENTER THE FRAME TOGETHER WITH WALLJAMBS ONTO THRESHOLD OF SHOWER BASE. Step 4 - ADJUST AND LEVEL THE FRAME ASSEMBLY. - MARK DRILLING LOCATION FOLLOWING PILOT HOLES. - REMOVE FRAME ASSEMBLY FROM BASE.
DOOR INSTALLATION STEPS 5A 5B Step 5 - INSERT THE WALL PLUGS (8) AND PUT IN EACH A DROP OF SILICONE.
DOOR INSTALLATION STEPS Step TOP TRACK 7 INSTALL THE FIXED PANELS (2) BY SECURING THEM WITH THE GLASS SUPPORTS (8) & SCREW 15/32” LG (4).
DOOR INSTALLATION STEPS Step 8 PRIOR TO INSTALL DOOR PANELS INSERT MAGNETIC DOOR GASKET (2) (OPTIONAL) ENFONCER PUSH DOWN 9C PUSH DOWN 9A INTERIOR SHOWER SIDE 9B INTERIOR SHOWER SIDE Step 9 INSERT DOOR PANELS INTO TOP & BOTTOM TRACK INTERIOR SHOWER SIDE PAGE 7
DOOR INSTALLATION STEPS Step 10 USE HEX NUT DRIVER OR PLIERS FOR VERTICAL DOOR ADJUSTMENT 10A LOOSEN TIGHTEN 10B 10D 10C 10E VERTICAL ADJUSTMENT Step INTERIOR SHOWER SIDE INSERT SIDE GASKET WALL JAMB SIDE (2) (both sides) 15 OR (FOR ‘’PARIS POINT ’’ GLASS ONLY) INTERIOR SHOWER SIDE TOP VIEW Step 11 INSTALL SIDE PANEL GASKET ONTO FIXED PANELS & DOOR PANELS (4) PAGE 8
DOOR INSTALLATION STEPS Step 12 - LEVEL AND ADJUST FRAME - FASTEN FRAME WITH SCREW 3/8” LG (8) + SCREW CAP (8) INTERIOR SHOWER SIDE B A INTERIOR SHOWER SIDE B INTERIOR SHOWER SIDE A PAGE 9
DOOR INSTALLATION STEPS Step 13 24 INSERT EXPANDER CAPS Hours Step 14 SILICONE EXTERIOR ON BOTH SIDES, ALONG THE WALL JAMBS AND WALLS. ALSO ALONG THE BOTTOM TRACK AND THE SIDE PANELS.
