Chapter 2 - Installation
2.1.3 Installing the 1x1 ODU
2.1.3.1 1x1 ODU (ODU-HP) Installation Requirements
2.1.3.1.1 ODU Packing List
 ODU
 Pole mounting kit
2.1.3.1.2 Additional Installation Requirements
The following items are also required to install the ODU:
 IF cable with two TNC connectors* (see Section 2.1.3 for details on IF cable
types and length).
 Antenna* and RF cable* for connecting the antenna to the ODU.
 Grounding cable with an appropriate termination.
 Installation tools and materials, including appropriate means (e.g. a 1" to 4"
pole) for installing the ODU and antenna.
2.1.3.2 Pole Mounting the ODU
The ODU can be mounted on a 1" to 4" pole using one of the following options:
 Special clamps and threaded rods are supplied with each unit. There are two
pairs of threaded holes on the back of the unit, enabling to use the clamps for
mounting the unit on diverse pole diameters.
 The protrusions with grooves on the top backsides of the unit, and the
protrusion on the bottom backside, enable the use of 9/16" wide metal bands
(not included with the package) to secure the unit to a pole.
NOTE
Items marked with an asterisk (*) are available from Alvarion.
NOTE
Install the unit with the bottom panel, which includes the LEDs, facing downward.
