User's Manual

Installing the ODU
4Motion System Manual 49
2.1.4 Installing the 4x2 ODU
2.1.4.1 AU-ODU Package Contents
 ODU (weight 15.5 kg +/- 1.5 kg)
 Four M10X30 screws
 Pole Mounting Kit: (weight ~6 kg)
» One Carriage for 4x2 ODU
» Four M10x265 Threaded Rods
» Eight M10 Nuts
» One M6X12 Grounding Screw
» Eight M10 Spring Washers
» Eight M10 Flat Washers
» Two M10 Clamps
2.1.4.2 Sun Guard Package Content
 4x2 ODU Sun Guard
 Four M6X16 screws
2.1.4.3 Pole Mounting Kit for Two ODUs Package Content (Optional)
 Two Carriage for 4x2 ODU
 Four M10x265 Threaded Rods
 Eight M10 Nuts
IMPORTANT
The weight of each ODU is 15.5 kg (+/- 1 kg) and the weight of the Pole Mounting
Kit is approximately 6 kg. Be sure to plan the installation accordingly. It is
recommended to use a harness to lift the units.
Install the AU-ODUs using the supplied kit only.
