Chapter 2 - Installation
 Antennas, including mounting kit (fixed and adjustable downtilt).
 Remote Cable Outdoor Termination Unit (3 Way AISG Breakout Box): One for
up to 3 antennas, 2 for 4 to 6 antennas.
 Long AISG Remote Cable (available in length of 60 or 80 meter).
 Remote Cable Termination Panel.
 Short AISG Remote Cables (available in length of 2, 3 or 5 meter according to
the distance of the Remote Cable Outdoor Termination Unit from the
antennas): One for each antenna. An additional cable is required if two Remote
Cable Outdoor Termination Units are used.
 Remote Downtilt Control Kit.
 RF cables for connecting the antenna to the ODU(s).
2.2.3 Recommended Installation Procedure
2.2.3.1 Pre-Installation
1 Connect the AISG Antenna Controller to each antenna to verify that it
functions properly. Check the address of each antenna and note it together
with its planned location (azymuth) for future reference. Note that an XX
antenna (4 ports antenna) has two bands, each with its own RET adjustment.
For details on using the AISG Antenna Controller refer to the documentation
supplied with it. Return the electronic downtilt to 0 degrees to ensure that the
indicator will not be damaged during installation.
2 Prepare the short AISG Remote Cables and connect them to the Remote Cable
Outdoor Termination Unit(s). If two Remote Cable Outdoor Termination Units
should be installed, prepare and connect also the cable interconnecting the
two units. Refer to the instruction supplied with the unit. Connect the
antennas and use the AISG Antenna Controller to verify proper operation.
Disconnect the antennas and Controller (and interconnecting cable if used).
2.2.3.2 Installation
1 Install the Remote Cable Termination Panel in a 19” rack. Its placement
should enable easy connection of the AISG Antenna Controller.
