Cyclone X8 Octocopter Instruction Manual 1 v1.
Contents 1. Safety Notes...........................................................................................................................................................................................................................................3 2. Check List..............................................................................................................................................................................................................................................
1. Safety Notes Do fly only in safe areas and always away from other people! Do not operate RC aircraft within the vicinity of homes or crowds of people. RC machine are prone to accidents, failures, and crashes due to a variety of reasons including pilot error, radio interference, and lack of maintenance. Pilot are responsible for their actions and damage or injury occurring during the operation of RC aircraft machine.
2. Check List Please Check the Follow parts. APC Propeller 14x4.7SFP (CW) 4 pcs APC Propeller 14x4.
Main Frame Body 1pcs Retract System Left Side 1 pcs Retract System Right Side 1 pcs Carbon Battery Tray 1 pcs Landing Skid Φ16*450mm + PVC Cover 2 sets H-frame Boom Φ12*450mm 2 pcs Carbon Arm Boom Φ22*380mm 4 pcs 12mm Boom Mount Set 8 sets Hexagon Screw Driver 1.5mm and 2.
3. Equipment Required For Assembly Transmitter (7CH or above) 1 pcs Receiver (7Ch or above) 1 pcs “X” Mode OctoCopter Controller (e.g. DJI WK-M/ A2 ) 1 pcs Connectors For Batteries and Power Board – 2 pairs 6S LiPo Battery 9000-20000mAh 22.2V (20C Min.
4 Assembly Steps – Motor and ESC 1.) Prepare your motors. 5.) Solder the other Ends to the Power/ ESC Board which is preinstalled inside the Main Frame Body. 2.) For the new motors, Thread Lock must be applied to the two M3 Set Screws which is pre-installed. 3.) Install the Porp Mount to the motor using 3pcs M3x8mm Hex Cap Screw. 6.) Parallel two ESCs. 7.) Solder Black and Red AWG wires to 2pcs of ESCs in Parallel. Same for other 3 pairs of ESCs. 7 4.
5.
5.
5.
Fixing the Arm Boom 14
6. Quick Collapsible Illustration Release two Thumbscrew and fold the four arms. Tighten the Thumbscrews before flying.
7.
8.
# Report any mistakes, please email to: info@alwarerc.com Related Videos could be found on: https://www.youtube.
