Specifications Sheet

AIA File #:
Specification #:
225 49th Ave. Dr. SW Cedar Rapids, IA 52404 U.S.A. | 800-233-2366 | 319-368-8120 | Fax: [phone] | www.acpsolutions.com
Amana® Commercial Microwave Model AOC24 | Heavy Volume
Specifications
Model AOC24 728028020847
Configuration Countertop or shelf
Control System Touch, angled for easy viewing
Programmable Control Pads 10
Braille Yes
Total Programmable Settings 100
Max. Cooking Time 10:00
Power Levels 11
Defrost Yes
Time Entry Option Yes
Microwave Distribution Rotating antennas, top and bottom
Magnetrons 2
Display LED
Stackable Yes
Stage Cooking Yes, 4
Door Opening Automatic opening
Signal Door automatically opens at end of cycle
Temp. Display Yes
Exterior Dimensions H 17 5/8” (448) W 13 5/8” (346) D** 19 3/16”(487)
Cavity Dimensions H 5 3⁄8” (136) W 11 3⁄4” (298) D 10” (254)
Door Depth n/a
Usable Cavity Space .319 cubic ft. (9 liter)
Exterior Finish Stainless steel
Interior Finish Stainless steel
Power Consumption 3100 W
Power Output* 2400 W* Microwave
Power Source 208/230V, 60 Hz, 20 A single phase
Plug Configuration / Cord NEMA 6-20 5 1/4” (133mm)
Frequency 2450 MHz
Product Weight 70 lbs. (32 kg.)
Ship weight (approx.) 73 lbs. (33 kg.)
Shipping Carton Size H 20
5
⁄8” (524 ) W 17” (432) D 22” (559)
UPS Shippable ISTA 3A approved small parcel
Specifications
Microwave oven door shall automatically open when
cooking cycle is complete. Door shall remain open
until ready to cook next item. To minimize space usage,
door shall open upwards. Control pad shall be angled for
easy viewing and located so door can be closed and
control pad pushed in one ergonomic motion. Control
pad shall be programmable with the ability to program
up to 100 menu items, single or double digit entry. There
shall be 11 power levels including defrost mode, and 4
cooking stages. Microwave shall have a 10-minute digital
countdown timer. Microwave output shall be 2400 watts.
Top and bottom magnetrons with rotating antennas shall
provide uniform heat distribution throughout the cav-
ity. Oven shall be stackable and have a compact, “jigsaw”
shaped footprint for back-to back placement on a 28
1
/2”
(724 mm) shelf or countertop using only 13
5
/8” (346mm) .
Oven cavity shall be stainless steel construction with
stainless oven door. Bottom of .319 cubic ft. (9 liter)
cavity shall be ceramic plate with a high temperature,
cleanable seal. Microwave oven shall comply with
standards set by the U.S Department of Health and Human
Services, and ETL Listed for both safety and sanitation.
Optional Accessories
Shelf extender accessory (OS10) attaches to an existing
shelf to extend it out to 28
1
/2” (724 mm).
Warranty
Warranty Certificate for this product can be found on the
ACP, Inc. website at:
www.acpsolutions.com/warranty
Service
All products are backed by our
24/7 ComServ Support Center.
Measurements in ( ) and not specified are millimeters
* IEC 60705 Tested
** Includes handle
© 2015 ACP, Inc.
Cedar Rapids, Iowa 52404
Part No. 20155202
Updated 8/24/15
Original Instructions
13-5/8”
(346)
17-5/8”
(448)
11-3/4”
(298)
5-3/8”
(136)
19-3/16”
(487)
front view
side view
3/8” (10) dia.
power cord
Interior dimensions
1-3/4”
(44)
10”
(254)
5’-1/4”
(1.6m)
1 1/4”
(32)
15-5/8”
(397)
2-1/2”
(64)
1-1/4
”
(32)
back view
11-1/8”
(283)
