Specification Sheet

SIRIO S2121(P/B)
DIMA DI FORATURA RADIATORE ELETTRICO SIRIO S2121(P/B) - (RS/RL)545008(SCALA 1:1)
TEMPLATE FOR THE DRILLING OF SIRIO ELECTRIC TOWEL WARMER S2121(P/B) - (RS/RL)545008 (SCALE1:1)
FORO PER INSERIMENTO TASSELLO A MURO 6x30
POSITIONING OF FASTENERS FOR FIXING TO WALL.
FASTNERS SHOULD BE SECURED IN STUDS OR HEADERS PLACES BEHIND THE UNIT
(RL/RS)545008
50 mm 1 15/16 "
MINIMUM
PAVIMENTO-PARETE INCASSO
FLOOR WALL FOR FITTING
SCHEMA CABLAGGIO
WIRING DIAGRAM
120 V
60 Hz
NERO - BLACK
(LINE)
INTERRUTTORE
SWITCH
VERDE -GIALLO
GREEN OR BARE COPPER
CAVO RADIATORE
WIRE FROM TOWEL
WARMER
CAVO RETE ELETTRICA
WIRE FROM POWER SOURCE
BIANCO - WHITE
(NEUTRAL)
VERDE
GREEN
SCATOLA IN PLASTICA
PLASTIC BOX
MURO
WALL
FASTON
PUNTO USCITA CAVO ELETTRICO
OUTLET FOR WIRE
INGOMBRO INTERNO SCATOLA ELETTRICA IN PLASTICA SU MURO
STANDARD SINGLE GANG JUNCTION BOX
542 mm
21 3/8 "
30 mm
1 3/16 "
482 mm
19 "
30 mm
1 3/16 "
67 mm 2 5/8 "
360 mm 14 3/16 "
117 mm 4 5/8 "
544 mm 21 7/16 "
SIDE VIEW
WALL-MURO
SCALE
1:3
76 mm 3 "
72 mm 2 13/16 "
598 mm 23 1/2 "
553 mm
21 3/4 "
= =
5 mm
3/16 "
70 mm
2 3/4 "
32 mm
1 1/4 "
102 mm
4 "
O
6 mm
1/4 "N° 4 FORI/HOLES
