Specification Sheet

AMC1080BC36-B
Amcrest FullHD 1080P Analog HDCVI Camera
Technical Specifications
Model
AMC1080BC36-B
Camera
Image Sensor
1/2.7” 2Megapixel CMOS
Effective Pixels
1920 (H) x 1080 (V)
Electronic Shutter
1/30s ~ 1/100,000s
Video Frame Rate
30fps@1080P
Synchronization
Internal
Min. Illumination
0.02Lux/F2.0, 0Lux IR on
Video Output
1CH BNC HD Video Output / CVBS SD Video Output
Camera Features
Night Vision
98 Feet, Smart IR
Backlight Compensation
DWDR
Day/Night
Auto (ICR) / B&W / Color
Noise Reduction
2D
Lens
Focal Length
3.6mm
Viewing Angle
90°
Mount Type
M12
General
Power Supply
DC12C±25%
Power Consumption
Max 4W
Working Environment
-40°F ~ 140°F / Less than 95% RH (no condensation)
Transmission Distance
Over 1640ft via 75-3 coaxial cable
Ingress Protection
IP67
Dimensions (W x D x H)
Φ2.75” x 6.5”
Weight
0.77 lbs.
Material
Metal (body) + Plastic (sunshield)
