User Guide

The DVR has connections for only 1 hard drive inside the case and the hard drive must be no

larger than 10TB (Terabytes).

To install your hard drive, the following is needed:

● A medium sized (regular) Phillips-head screwdriver - not included

● A hard drive - not included (unless you purchased a ‘kit’ that does have one included)

● Four hard drive fastening screws – included

Note: Before installing the hard drive, make sure the DVR is powered off and completely

disconnected from power.

1. Loosen the screws on the

upper cover and side panel.

2. Attach four screws on the

HDD (Do not fully tighten, only

tighten about 3 times).

3. Place the HDD in

accordance with the four holes

on the bottom of the casing.

4. Turn the DVR upside down

and place the screws in firmly.

5. Tighten the HDD screws

firmly to the bottom of the

DVR.

6. Connect the HDD cable and

power cables to the

motherboard.

7. Put the cover back onto the DVR

in accordance with the clip and then

place the upper cover back onto the

device.

8. Secure the screws on the rear

and side panels.
