www.amp-research.com

1/10

IM75146 rev 08.06.13

I N S T A L L A T I O N G U I D E

Scan the QR code with your smartphone to view videos on YouTube.

3-5 Hours

Professional installation recommended

http://youtu.be/i7tkWahELEY

http://youtu.be/da2n8KxwasU

Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:

Printed in USA.

TOOLS REQUIRED

qSafety goggles

qMeasuring tape

qPower Drill

q9/32” drill bit

q10 mm socket

q13 mm socket

q21 mm socket

qRatchet wrench and extension

qWire crimpers

qWire stripper / cutter

q3/16” hex key wrench (allen wrench)

q4mm hex key wrench ( allen wrench )

qElectrical tape

qWeather proof caulking (silicone sealer)

qSilicone spray

INSTALLATION TIME

2 3

SKILL LEVEL

4= Experienced

AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2)

Monday - Friday, 6:00 AM - 5:00 PM PST

APPLICATION AMP Part #

Chevrolet Silverado / GMC Sierra - Crew Cab 2011 - 2014 75146-01A (Diesel Only)

Chevrolet Silverado / GMC Sierra - Ext Cab 2011 - 2014* 75146-01A (Diesel Only)

*Modification required to running board assembly. See Item 1 on page 3.

5-Year Limited Warranty

WARRANTY

Summary of content (11 pages)

PAGE 1
INSTALLATION GUIDE APPLICATION AMP Part # Chevrolet Silverado / GMC Sierra - Crew Cab 2011 - 2014 75146-01A (Diesel Only) Chevrolet Silverado / GMC Sierra - Ext Cab 75146-01A (Diesel Only) 2011 - 2014* *Modification required to running board assembly. See Item 1 on page 3. INSTALLATION TIME 3-5 Hours Professional installation recommended SKILL LEVEL 1 2 3 4 4= Experienced TOOLS REQUIRED Scan the QR code with your smartphone to view videos on YouTube.
PAGE 2
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C INSTALLATION GUIDE Attaching motor to Linkage assembly. To be assembled in Step 6. Exploded View 80-03129-90 Motor 19-03179-90 Socket cap screw 19-03133-90 Washer 19-03138-90 Drive Gear Housing Cover CAUTION: HANDLE WITH CARE. The motor must be put on in Step 6 after the linkage is tightened to the body of the vehicle.
PAGE 3
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C Note: Some Applications require modification.
PAGE 4
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C 6 19-03297-A06 Controller 9 7 x6 19-03326-90 Hex Bolt 5 10 x8 19-02802-90 Socket Cap Screw 11 x2 20-03759-90 Fender Spacer 19-03354-90 Posi-Tap™ x2 19-03467-90 U-nut x2 17-03500-90 Threaded Clamping Plate 14 x20 19-02805-90 Cable tie (7”) x4 8 16-03014-90 Washer 13 16 x6 x4 19-03302-90 LED Lamp www.amp-research.
PAGE 5
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C Remove Passenger and Driver side Fender and body mount bolt. Body mount bolt will be reused. Install front Idler Linkages. Install Passenger and Driver side Motor Linkage in fourth sheetmetal tab / hole from front. Extra Cab: See measurements below for location.
PAGE 6
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C 8 Install motor onto Motor Linkage Assembly. See page 2 for motor installation instructions. Using the two 11” cable ties, mount controller to the support arm next to the battery. 6 7 Plug in wire harness. (Ensure that locking tabs engage.) Attach power lead (RED wire) to positive pole on the battery and Negative lead (BLACK wire) to negative pole on the battery. CAUTION: Do not ground wrench when engaged Remove fuse from harness.
PAGE 7
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C IMPORTANT: Step 16 and 17 are for Crew Cab trucks only. (Not used on Extended Cab Trucks) (Light Blue and Green wires are only used with Crew Cab trucks.) Pop off the threshold cover with screwdriver and remove the kick panel. Repeat step on passenger side.
PAGE 8
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C Remove plastic trim on door near mirror attachment. Then carefully pry up window/ door lock switch plate. 19 18 To remove door panel, first pry back tab on door lock to remove then pry off plastic covers by handle and door latch. Remove the 3 door bolts and then remove door panel by prying loose all panel fasteners. Remove door latch cable from door panel.
PAGE 9
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C Locate loom that runs across the top of the door panel. Carefully remove wire wrap and locate the following wires on either side. Drivers side: Grey / Black wire Passenger side: Tan / White wire Cau- On each side of the vehicle measure from the front edge of door line on the pinch weld to the specified lengths below. Measure at 22” for front LED Light and 65” for rear LED Light.
PAGE 10
A M P R E S E A R C H P O W E R S T E P TM – C H E V R O L E T / G M C - Check that all doors activate the Power Step and the LED Lights work when doors open and close. Reinstall any remaining trim panels. FINAL SYSTEM CHECK Check that all doors activate the PowerStep and the LED lights work when doors open and close. NORMAL OPERATION: When the doors open, PowerStep automatically deploys from under the vehicle.
PAGE 11
™ Congratulations on your purchase of the genuine AMP Research PowerStep! Here’s what you should know... AMP Research PowerStep running boards automatically move when the doors are opened to assist entering and exiting the vehicle. Automatic power deploy: The running boards will extend down and out when the doors are opened. Automatic power stow: The running boards will return to the stowed position when the doors are closed.
