Upgrading Firmware
96
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Uploading IR Codes to the MVP-5100
Since the MVP-5100 communicates with other devices through IR instead of through WiFi, making sure
that the device has the latest IR codes is vital. To ensure that the IR codes installed on the device are the
most suitable, use NetLinx Studio to upload newly available codes via the AMX IRN database.
All IR code files used by NetLinx Studio are in the .IRN format. These may be created via IREdit
(available from www.amx.com), supplied from a personal IRN database, or from the AMX IRN
database. To access the available IRN files:
1. Launch NetLinx Studio.
2. Open the NetLinx Workspace (FIG. 74).
3. Right-click on the IR folder and select the method to add the necessary IR files.
Add Existing IR File... chooses from a previously downloaded IR file (please refer to the
Adding an existing IR file to NetLinx Studio section on page 98 for specific procedures)
Add From AMX IR Database... chooses from AMX’s IR file database (please refer to the
Adding an AMX IR Database file to NetLinx Studio section on page 99 for specific
procedures).
Add From User IR Database... chooses from a personal IR file database (please refer to the
Adding a personal IR Database file to NetLinx Studio section on page 101 for specific
procedures).
Installation of IR files on the MVP-5100 requires use of the latest version of NetLinx
Studio, available from www.amx.com.
FIG. 74 NetLinx Studio Workspace Tree
