Programming
111
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Font Styles and ID Numbers
Font styles can be used to program the text fonts on buttons, sliders, and pages. The following chart
shows the default font type and their respective ID numbers generated by TPDesign4.
Border Styles and Programming Numbers
Border styles can be used to program borders on buttons, sliders, and popup pages.
Default Font Styles and ID Numbers
Font ID # Font type Size Font ID # Font type Size
1 Courier New 9 19 Arial 9
2 Courier New 12 20 Arial 10
3 Courier New 18 21 Arial 12
4 Courier New 26 22 Arial 14
5 Courier New 32 23 Arial 16
6 Courier New 18 24 Arial 18
7 Courier New 26 25 Arial 20
8 Courier New 34 26 Arial 24
9 AMX Bold 14 27 Arial 36
10 AMX Bold 20 28 Arial Bold 10
11 AMX Bold 36 29 Arial Bold 8
32 - Variable Fonts start at 32.
Fonts must be imported into a TPDesign4 project file. The font ID numbers are
assigned by TPDesign4. These values are also listed in the Generate
Programmer’s Report.
Border Styles and Programming Numbers
No. Border styles No. Border styles
0-1 No border 10-11 Picture frame
2 Single line 12 Double line
3 Double line 20 Bevel-S
4 Quad line 21 Bevel-M
5-6 Circle 15 22-23 Circle 15
7 Single line 24-27 Neon inactive-S
8 Double line 40-41 Diamond 55
9 Quad line
